Consolidated RNA6911 P5 needle roller bearing, no inner ring, 63 mm roller bore, 80 mm OD, 45 mm wide, double row, P5 precision. Same envelope as INA RNA6911.
List Price
$40.46
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Consolidated |
|---|---|
| MPN | RNA6911 P5 |
| GTIN | 644075091190 |
| Model | RNA 6911 P5 |
| Bearing Type | Needle Roller Bearing, Open |
| ID | 63 mm |
| OD | 80 mm |
| Width | 45 mm |
| Material | Chrome Steel |
|---|---|
| Series | RNA69 |
| Condition | New |
| Rolling Elements | Needle Roller |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.40.00.00 |
| Overall Width | 45 mm |
| Mpn Variants | RNA6911 P5, RNA6911P5, RNA-6911, RNA 6911, RNA6911 |
| Precision Class | ABEC 5 / P5 |
| Cross Reference 1 | INA RNA6911 |
|---|---|
| Cross Reference 2 | IKO RNA6911 |
| Cross Reference 3 | NTN RNA6911R |
| Cross Reference 4 | Koyo RNA6911 |
| Cross Reference 5 | SKF RNA 6911 |
The Consolidated RNA6911 P5 is a machined-ring needle roller bearing without an inner ring, double row, ISO 69 dimension series. Roller Set Bore (Fw): 63 mm. Outside Diameter: 80 mm. Width: 45 mm. Precision Class: P5.
RNA — needle roller bearing with machined outer ring, no inner ring. The needle rollers run directly on a hardened and ground shaft.
69 — ISO dimension series 69, two rows of needle rollers.
11 — size code: 63 mm roller set bore, matching the NA6911 with inner ring (55 mm bore).
P5 — ISO tolerance class 5.
Bearing Type: Needle Roller Bearing. Inner Ring: None. Number Of Rows: 2. Rolling Elements: Needle Roller. Roller Set Bore (Fw): 63 mm. Outside Diameter: 80 mm. Width: 45 mm. Precision Class: ABEC 5 / P5. Brand: Consolidated. Unit Quantity: 1 Pc.
Envelope: 63 x 80 x 45 mm. Shaft raceway diameter: 63 mm. With inner ring the equivalent bearing is NA6911, 55 x 80 x 45 mm.
Same envelope as INA RNA6911, IKO RNA6911, NTN RNA6911R, Koyo RNA6911 and SKF RNA 6911.
What are the dimensions of an RNA6911?
Roller Set Bore (Fw): 63 mm. Outside Diameter: 80 mm. Width: 45 mm.
Does the RNA6911 have an inner ring?
No. The rollers run on the shaft. The version with inner ring is the NA6911.
How many rows of rollers?
Two. Number Of Rows: 2.
