Double row cylindrical roller bearing, 110x170x45 mm, 1:12 tapered bore, machined brass cage, ABEC 7 / P4 super-precision spindle bearing.
List Price
$374.64
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | NN3022MBKRCC1P4 |
| Model | NN 3022 MB KR CC1 P4 / NN3022-AS-K-M-SP |
| Bearing Type | Cylindrical Roller Bearing, Open |
| ID | 110 mm |
| OD | 170 mm |
| Width | 45 mm |
| Material | Bearing Steel |
|---|---|
| Series | NN30 double row cylindrical roller |
| Lubricant | Grease or oil |
| Base Number | NN3022 |
| Industry Terms | Double row cylindrical roller bearing; precision spindle bearing; tapered bore roller bearing; machine tool bearing |
| Common Misspellings | NN3022MBKRCCIP4; NN 3022MBK RCC1P4; NN3202MBKRCC1P4; NN3022MBKRCC1-P4 |
| Application Types | Machine tool spindles; lathe and milling headstocks; grinding machines; heavy radial precision shafting |
| Overall Width | 45 mm |
| Mpn Variants | NN3022MBKRCC1P4; NN3022 MB K R CC1 P4; NN-3022-MB-K-R-CC1-P4; NN3022KMBP4; NN3022K |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | da min 119 mm; Da min 157 mm; Da max 161 mm; r min 2 mm; ra max 2 mm |
| Cage Type | Machined |
| Dynamic Load Rating | 281,000 N |
| Static Load Rating | 375,000 N |
| Rolling Elements | Cylindrical Roller |
| Item Weight | 3.71 kg (8.18 lb) |
| Cage Material | Brass |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | Without Snap Ring |
| Limiting Speed | 3,400 rpm grease; 4,300 rpm oil |
| Harmonization Code | 8482.50 |
| Mounting Arrangement | Single bearing on a 1:12 tapered spindle journal, no adapter sleeve |
| Bearing Material | Bearing steel |
| Cross Reference 1 | FAG NN3022-AS-K-M-SP |
|---|---|
| Cross Reference 2 | SKF NN 3022 K – standard class, not P4 |
| Cross Reference 3 | Koyo NN3022K – standard class, not P4 |
| Cross Reference 4 | NTN NN3022K – standard class, not P4 |
| Cross Reference 5 | NSK NN3022K – standard class, not P4 |
| Cross Reference 6 | NSK NN3022 – cylindrical bore, not tapered |
NSK NN3022MBKRCC1P4 is a double row cylindrical roller bearing of the NN3022K type, built to super-precision tolerances with a tapered bore and a machined brass cage. Bore Diameter: 110 mm. Outside Diameter: 170 mm. Overall Width: 45 mm. Rolling Elements: Cylindrical Roller. Number Of Rows: 2. Closure Type: Open. Bearing Material: Bearing steel. Series: NN30 double row cylindrical roller. Base Number: NN3022.
NN — double row cylindrical roller bearing.
3022 — 30 dimension series, 110 mm bore.
MB — machined brass cage.
K — 1:12 tapered bore.
P4 — ISO class 4 precision, ABEC 7 equivalent.
Dynamic Load Rating: 281,000 N. Static Load Rating: 375,000 N. Limiting Speed: 3,400 rpm grease; 4,300 rpm oil. Precision Class: ABEC 7 / P4. Cage Material: Brass. Cage Type: Machined. Item Weight: 3.71 kg (8.18 lb). The two roller rows carry radial load only; axial location comes from a separate thrust member in the spindle.
Bore Type: Tapered 1:12. Shaft abutment diameter da min: 119 mm. Housing abutment diameter Da: 157–161 mm. Chamfer r min: 2 mm. Fillet radius ra max: 2 mm. Lubricant: Grease or oil. The tapered bore seats directly on a matching 1:12 taper on the spindle journal; no adapter sleeve is used. Driving the inner ring up the taper expands it and sets the running clearance.
Unit Quantity: 1 Pc. Mounting Arrangement: Single bearing, radial location on a tapered journal.
FAG NN3022-AS-K-M-SP is the super-precision, machined brass cage, tapered bore match on the 110 · 170 · 45 mm size. SKF NN 3022 K, Koyo NN3022K, NTN NN3022K and NSK NN3022K share the size, the two roller rows and the 1:12 tapered bore but are standard class, not P4. The NN3022 with a cylindrical bore is a different bore form.
