Availability:
1 in stock
Single-row cylindrical roller bearing, 65 x 120 x 23 mm, straight bore, non-locating NU design, open, machined brass cage, CN clearance. 6700 rpm limit.
List Price
$78.76
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | NU213M |
| Model | NU213 M |
| Bearing Type | Cylindrical Roller Bearing, Open |
| ID | 65 mm |
| OD | 120 mm |
| Width | 23 mm |
| Material | Bearing Steel |
|---|---|
| Base Number | NU213 |
| Industry Terms | cylindrical roller bearing; NU bearing; floating bearing position; brass cage roller bearing; radial roller bearing |
| Common Misspellings | NU 213M; NU213-M; FAG NU213MB; NU213N |
| Application Types | Electric motors; gearboxes; pumps; blowers; machine tool and heavy shaft floating positions |
| Bore Shaft Size | 65 mm |
| Mpn Variants | NU213M; NU 213 M; NU-213-M; NU213; NU213MBL |
| Rolling Elements | Cylindrical Rollers |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Part Number | NU213M |
A FAG NU213M single-row cylindrical roller bearing, 65 mm bore, 120 mm outside diameter, 23 mm width. Straight bore, open, machined brass cage, normal precision class, CN internal clearance.
NU is the non-locating cylindrical roller design: guide ribs on the outer ring, plain cylindrical inner ring. The 2 marks the 02 dimension series and the bore code 13 gives 65 mm. M is the machined brass cage. No clearance suffix follows, so internal clearance is CN and the class is normal.
An NU bearing carries radial load only and lets the shaft float axially relative to the housing, which makes it the free bearing position where thermal growth has to be accommodated. Line contact between roller and raceway gives several times the radial rating of a ball bearing in the same envelope. The machined brass cage is roller-guided, tolerates higher temperature and heavier shock than pressed steel, and suits oil-lubricated high-speed duty up to the 6700 rpm limiting speed.
1 Pc. Complete bearing: ribbed outer ring, roller and brass cage assembly, plain inner ring. Open both faces, without snap ring.
The plain inner ring separates from the outer ring, so it can be heated and fitted to the shaft on its own. Axial location of the shaft comes from the second bearing in the arrangement.
SKF NU 213 ECM and NTN NU213M are same-spec equivalents at this envelope and clearance. NJ213M is a related size with one inner-ring rib that locates the shaft in one direction; NUP213M is a related size that locates in both.
