A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
MRC 212MFG filling-notch deep groove ball bearing, 60 x 110 x 22 mm, one shield and snap ring, 56,100 N dynamic rating. Cross-reference NSK BL212ZNR.
List Price
$40.26
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | MRC |
|---|---|
| MPN | 212MFG |
| Model | 212 MFG |
| Bearing Type | Ball Bearing, Single Shield |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Series | MRC 200-M Light Series |
|---|---|
| Dynamic Load Rating | 56,100 N |
| Static Load Rating | 51,000 N |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Yes |
| Limiting Speed | 4,900 rpm grease; 6,000 rpm oil |
| Mpn Variants | 212MFG, 212-MFG, 212 MFG, 212-M-FG |
| Compatible With Replaces | NSK BL212ZNR |
| Additional Attributes | Max Fillet Radius: 1.5 mm; Construction: maximum-capacity filling-notch (Max type) |
| Cross Reference 1 | NSK BL212ZNR |
|---|---|
| Cross Reference 2 | 6212-Z/NR (related, Conrad type) |
The MRC 212MFG is a single-row, maximum-capacity filling-notch deep groove ball bearing from the MRC 200-M Light Series, with one shield and a snap ring on the outer ring. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. The filling notch admits a larger ball complement than a Conrad bearing of the same envelope, raising radial capacity.
212 — 200 light series, 60 mm bore.
M — maximum-capacity filling-notch (Max type) construction.
F — one shield; the opposite face is open.
G — snap ring fitted in an outer-ring groove for axial location in the housing.
Dynamic Load Rating: 56,100 N. Static Load Rating: 51,000 N. Limiting Speed: 4,900 rpm grease; 6,000 rpm oil. Closure Type: Shield one side. Snap Ring: Yes. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Series: MRC 200-M Light Series. Unit Quantity: 1 Pc.
Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Max Fillet Radius: 1.5 mm.
Cross-Reference 1: NSK BL212ZNR, filling-notch type. Cross-Reference 2: 6212-Z/NR, Conrad type with a smaller ball complement and lower load ratings. MPN Variants: 212MFG, 212-MFG, 212 MFG, 212-M-FG.
It is a single-row filling-notch deep groove ball bearing, 60 x 110 x 22 mm, with one shield and a snap ring on the outer ring.
Dynamic load rating is 56,100 N and static load rating is 51,000 N. Limiting speed is 4,900 rpm on grease and 6,000 rpm on oil.
The filling notch admits a larger ball complement than a Conrad bearing of the same envelope, raising radial capacity.
