Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
2 in stock
Super-precision spindle angular contact ball bearing, 30 x 55 x 13 mm, 25 degree contact angle, ABEC 7 / P4A. Matched set of two, extra light preload.
List Price
$206.51
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7006ACXP4ADGA |
| Model | 7006 A CX P4A DGA 7006ACXGAP4A |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 30 mm |
| OD | 55 mm |
| Width | 13 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Series | 7000 |
| Lubricant | None |
| Preload | Extra light preload |
| Total Width | 26 mm |
| Arrangement Configuration | Matched set of two |
| Precision Class | ABEC 7 / P4A |
| Additional Attributes | eCl@ss 23-05-08-04; UNSPSC 31171531; indicative carbon footprint 0.81 kg CO2e |
| Cage Type | Outer-ring shoulder-guided |
| Dynamic Load Rating | 22,100 N (matched set of two) |
| Static Load Rating | 15,300 N (matched set of two) |
| Precision Rating | ABEC 7 / P4A |
| Rolling Elements | Ball |
| Item Weight | 0.219 kg (0.48 lb) per matched pair |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mounting Arrangement | Universally matchable: back-to-back (DB), face-to-face (DF) or tandem (DT) |
| Bearing Material | Bearing steel |
| Cross Reference 1 | SKF 7006 ACD/P4ADGA (SKF replacement, same preload) |
|---|---|
| Cross Reference 2 | FAG B7006-E-T-P4S (confirm preload code) |
| Cross Reference 3 | NSK 7006A5TYNSULP4 (light preload) |
| Cross Reference 4 | RHP 7006A5TDULP4 (light preload pair) |
SKF 7006 ACX/P4ADGA is a matched set of two super-precision, high-capacity D design, single row angular contact ball bearings. SKF lists 7006 ACD/P4ADGA as the replacement for this designation, and the figures below are SKF’s published data for that replacement. Bore Diameter: 30 mm. Outside Diameter: 55 mm. Overall Width: 13 mm per bearing. Total Width: 26 mm across the matched pair. Contact Angle: 25°. Precision Class: ABEC 7 / P4A. Rolling Elements: Ball. Number Of Rows: 1 per bearing. Bore Type: Straight. Closure Type: Open. Seal type: Open. Bearing Material: Bearing steel. Unit Quantity: 2 Pcs.
7006 — ISO 70 light dimension series, bore code 06, giving a 30 x 55 x 13 mm envelope per bearing.
A — 25° contact angle.
P4A — SKF super-precision tolerance class P4A, ABEC 7 running accuracy.
DGA — universally matchable set of two bearings, extra light preload.
Dynamic Load Rating: 22,100 N. Static Load Rating: 15,300 N. Both are SKF set ratings covering the two bearings together. Design: high-capacity D. Contact type: normal contact, two-point. Ring type: one-piece inner and outer rings. Matched condition: extra light preload. The set is preload-adjusted at the factory and therefore carries no internal clearance class. Coating: without. Sealing: without. Lubricant: none.
Item Weight: 0.219 kg (0.48 lb) per matched pair. Indicative carbon footprint for a new product: 0.81 kg CO2e. eCl@ss code: 23-05-08-04. UNSPSC code: 31171531. Harmonization Code: 8482.10.50.
Mounting Arrangement: universally matchable, back-to-back (DB), face-to-face (DF) or tandem (DT). Arrangement / Configuration: matched set of two. Number of bearings in the matched set: 2. Unit Quantity: 2 Pcs. Cage Type: outer-ring shoulder-guided. Snap ring included: No.
SKF 7006 ACD/P4ADGA is SKF’s own named replacement for this designation. Other equivalent 30 x 55 x 13 mm 25° super-precision executions: FAG B7006-E-T-P4S, NSK 7006A5TYNSULP4, RHP 7006A5TDULP4. Makers whose super-precision schemes carry no 25° letter on this series are left unlisted so that a 15° or 30° execution is not offered as an interchange.
