Availability:
1 in stock
MRC 7208DU angular contact ball bearing, 40 x 80 x 18 mm, 29° contact angle, 30,700 N dynamic rating. Single universally ground bearing for DB, DF or DT pairs.
List Price
$45.11
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | MRC |
|---|---|
| MPN | 7208DU |
| Model | 7208DU |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 40 mm |
| OD | 80 mm |
| Width | 18 mm |
| Series | 7200 |
|---|---|
| Dynamic Load Rating | 30,700 N |
| Static Load Rating | 22,800 N |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 7,700 rpm grease |
| Harmonization Code | 84821000 |
| Contact Angle | 29° |
| Mounting Arrangement | Universal (DB, DF or DT) |
| Base Number | 7208 |
| Industry Terms | Angular contact ball bearing; universally ground bearing; matched pair half; spindle bearing; 29 degree angular contact bearing |
| Common Misspellings | 7208 DU; 7208UD; 7208-D-U; MCR 7208DU; anglular contact bearing; angular contact bearring |
| Total Width | 18 mm |
| Overall Width | 18 mm |
| Bore Shaft Size | 40 mm |
| Mpn Variants | 7208DU; 7208-DU; 7208 D U; 7208D |
| Arrangement Configuration | Single universally ground bearing, one half of a matched pair |
| Design Units | Metric |
| Part Number | 7208DU |
| Application Types | machine tool spindles; pumps; gearheads; precision machinery |
| Cross Reference 1 | NSK 7208A (30°, related size) |
|---|---|
| Cross Reference 2 | Koyo 7208 (30°, related size) |
| Cross Reference 3 | NTN 7208 (30°, related size) |
MRC 7208DU single-row angular contact ball bearing from the MRC 7200 light series, 40 mm bore, 80 mm outside diameter and 18 mm wide, with a 29° contact angle. Single universally ground bearing, one half of a pair. Unit Quantity: 1 Pc.
7208 — MRC 7200 light angular contact series, 08 bore code, 40 x 80 x 18 mm. No type letter: 29° contact angle, counterbored outer ring.
DU — single bearing, universally ground for duplex mounting back-to-back, face-to-face or tandem.
Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 18 mm. Contact Angle: 29°. Dynamic Load Rating: 30,700 N. Static Load Rating: 22,800 N. Limiting Speed: 7,700 rpm grease. Closure Type: Open. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Mounting Arrangement: Universal (DB, DF or DT). Harmonization Code: 8482.10.
Straight bore for a 40 mm shaft seat; 80 mm housing bore. Pairs with a second 7208DU in DB, DF or DT arrangement.
Related sizes in the same 40 x 80 x 18 mm envelope at a 30° angle: NSK 7208A, Koyo 7208, NTN 7208. Also written as 7208DU, 7208-DU, 7208 D U and 7208D.
40 x 80 x 18 mm with a 29° contact angle.
Dynamic Load Rating 30,700 N, Static Load Rating 22,800 N, Limiting Speed 7,700 rpm grease.
A single bearing universally ground for duplex mounting in DB, DF or DT arrangement.
