MRC5210CFGDouble Row Angular Contact Ball Bearing – 50 mm ID, 90 mm OD, 30.16 mm (1-3/16 in) Width, One Shield, Snap Ring, 30° Contact Angle

Product Description

What this part is:

MRC 5210CFG, a double-row angular contact ball bearing from the MRC 5200-C light series: 50 mm bore, 90 mm outside diameter, 30.16 mm (1-3/16 in) width, one shield and a snap ring on the outer ring. Two opposed rows carry radial load and axial load in both directions from a single position. Unit Quantity: 1 Pc.

Decoding the designation:

5210 — MRC 5200 light double-row series, bore code 10, 50 mm bore; the ISO 3210 section.

C — MRC 5200-C execution, 30.16 mm (1-3/16 in) width.

F — one shield; the opposite face is open.

G — snap ring groove in the outer ring with snap ring fitted, for axial location in a plain housing bore.

Specifications:

Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 30.16 mm (1.1875 in). Contact Angle: 30°. Dynamic Load Rating: 48,800 N. Static Load Rating: 39,000 N. Limiting Speed: 4,800 rpm grease; 6,300 rpm oil. Closure Type: Shield one side. Snap Ring: Yes. Number Of Rows: 2. Rolling Elements: Ball. Bore Type: Straight. Series: 5200-C. Country of Origin: United States. Unit Quantity: 1 Pc.

Dimensions and mounting:

Envelope 50 x 90 x 30.16 mm. The outer-ring snap ring groove with ring fitted locates the bearing axially in a plain housing bore.

Compatibility and replacement:

Same 50 x 90 x 30.2 mm double-row envelope with one shield and snap ring: SKF 3210 A-ZNR and NSK 3210 BZNR. FAG 3210-B-Z-TVH has no snap ring. Alternate written forms: 5210CFG, 5210-CFG, 5210 CFG, 5210-C-F-G, 5210C, 3210.

Frequently asked questions:

What is the contact angle of the MRC 5210CFG?

30°.

What closure does it have?

One shield on one face, the opposite face open, with a snap ring on the outer ring.

What are its load ratings?

Dynamic Load Rating 48,800 N and Static Load Rating 39,000 N.
