Super precision angular contact ball bearing, 110 x 150 x 20 mm, 25 degree contact angle, phenolic cage, light preload, 8,000 rpm grease limiting speed.
List Price
$457.60
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | B71922E.T.P4S.K5.J15F.UL |
| GTIN | 4012801457989 |
| Model | B-71922-ETP4SK5J15FUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 150 mm |
| Width | 20 mm |
| Material | Chrome steel |
|---|---|
| Preload | Light |
| Base Number | 71922 |
| Industry Terms | Spindle bearing, super precision bearing, machine tool bearing, high speed angular contact bearing |
| Bore Shaft Size | 110 mm |
| Mpn Variants | B71922ETP4SK5J15FUL, B71922-E-T-P4S-K5-UL-J15F, B71922E.T.P4S.UL, B-71922-ETP4SK5J15FUL, 7922, 71922ACDP4A |
| Dynamic Load Rating | 58,000 N |
| Static Load Rating | 44,500 N |
| Series | B719 |
| Rolling Elements | Ball |
| Item Weight | 0.85 kg (1.87 lb) |
| Cage Material | Laminated fabric phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Limiting Speed | 8,000 rpm grease; 12,000 rpm oil |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 25° |
| Part Number | B71922E.T.P4S.K5.J15F.UL |
| Precision Class | P4S |
| Closure Type | Open |
| Cross Reference 1 | SKF 71922 ACDGA/P4A - class P4A vs P4S |
|---|---|
| Cross Reference 2 | Fafnir 3MM9322WI - class P4 vs P4S |
| Cross Reference 3 | FAG B71922C.T.P4S.UL - 15 deg vs 25 deg |
FAG B71922E.T.P4S.K5.J15F.UL is a super-precision single-row angular contact ball bearing, also called a spindle bearing. Series B719. Bore 110 mm, outside diameter 150 mm, width 20 mm. Open, straight bore. Universal single bearing for mounting in pairs or sets. Sale unit: 1 Pc. GTIN: 4012801457989.
B719 — FAG ISO 719 dimension series, 110 x 150 x 20 mm at bore code 22.
E — 25° contact angle.
T — laminated fabric phenolic cage.
P4S — FAG precision class P4S.
UL — universal single bearing, light preload when mounted in a pair.
Bore Diameter: 110 mm. Outside Diameter: 150 mm. Width: 20 mm. Contact Angle: 25°. Number of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Cage Material: Laminated fabric phenolic. Precision Class: P4S. Preload: Light. Dynamic Load Rating: 58,000 N. Static Load Rating: 44,500 N. Fatigue Load Limit: 4,150 N. Limiting Speed: 8,000 rpm grease; 12,000 rpm oil. Item Weight: 0.85 kg (1.87 lb). Bearing Material: Chrome steel.
Preload force in a light-preload pair: 455 N. Axial rigidity in light preload: 225 N/µm.
Diameter of shaft shoulder: 117 mm. Shoulder diameter of outer ring: 143 mm. Maximum recess radius: 0.6 mm. Minimum chamfer dimension: 1.1 mm. Distance between the apexes of the pressure cones: 40.3 mm. Operating temperature range: -30 °C to 100 °C.
Cross-references: SKF 71922 ACDGA/P4A, class P4A against P4S. Fafnir 3MM9322WI, class P4 against P4S. Related part: FAG B71922C.T.P4S.UL with a 15° contact angle. Base designation: B71922E.T.P4S.UL. MPN variants: B71922ETP4SK5J15FUL, B71922-E-T-P4S-K5-UL-J15F, B-71922-ETP4SK5J15FUL, 7922.
25°, from the E code.
Bore 110 mm, outside diameter 150 mm, width 20 mm.
Dynamic 58,000 N, static 44,500 N, limiting speed 8,000 rpm on grease and 12,000 rpm on oil.
