FAG B71905-E-T-P4S-UL angular contact ball bearing, 25 mm bore x 42 mm OD x 9 mm width, 25° contact angle, phenolic cage, P4. Universal, light preload.
List Price
$122.99

2 in stock
On the Shelf & Ready to Ship
Ships same day by 6pm ET

No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | B71905-E-T-P4S-UL |
| Model | B71905ETP4SUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 25 mm |
| OD | 42 mm |
| Width | 9 mm |
| Material | Bearing Steel |
|---|---|
| Series | 71900 |
| Preload | Light |
| Precision Class | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mpn Variants | B71905ETP4SUL; B71905E.T.P4S.UL; B71905-E-T-P4S-UL; B 71905 E T P4S UL; B71905E |
| Closure Type | Open |
| Cross Reference 1 | NSK 7905A5TRSULP4 - 25 deg, phenolic cage, light preload, P4 |
|---|
FAG B71905-E-T-P4S-UL is a new super-precision single-row angular contact ball bearing in the universal design. Bore Diameter: 25 mm. Outside Diameter: 42 mm. Overall Width: 9 mm. Contact Angle: 25°. Unit Quantity: 1 Pc.
71905 — ISO 719 series size, 25 mm bore (05 x 5).
E — 25° contact angle.
T — phenolic cage.
UL — universal design, light preload.
Series: 71900. Contact Angle: 25°. Cage Material: Phenolic. Precision Class: ABEC 7 / P4. Preload: Light. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Closure Type: Open. Material: Bearing Steel.
Bore Diameter: 25 mm. Outside Diameter: 42 mm. Overall Width: 9 mm.
NSK 7905A5TRSULP4 is the closest cross-reference (25°, phenolic cage, universal light preload, P4). Also written as B71905ETP4SUL, B71905E.T.P4S.UL and B 71905 E T P4S UL.
Bore Diameter: 25 mm. Outside Diameter: 42 mm. Overall Width: 9 mm.
The E designates a 25° contact angle.
T is a phenolic cage. UL is the universal design with light preload.
