Availability:
8 in stock
Single-row angular contact ball bearing, 90 x 160 x 30 mm, 40° contact angle, polyamide cage, ISO P5 precision. Sold as 1 Pc.
List Price
$191.23
8 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 7218B.TVP.P5 |
| Model | 7218 B TVP P5 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 90 mm |
| OD | 160 mm |
| Width | 30 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Lubricant | Grease |
| Base Number | 7218 |
| Industry Terms | angular contact ball bearing, 40 degree bearing, thrust ball bearing, precision spindle bearing, P5 bearing, TVP cage bearing |
| Common Misspellings | 7218BTVP P5, 7218B TVPP5, 7218 BTVP, FAG 7218 BTVPP5, 7218B.TPV.P5, FAG 7128B.TVP.P5 |
| Application Types | machine tool spindles, pumps, gearboxes, compressors, industrial fans, vertical shaft assemblies |
| Bore Shaft Size | 90 mm (3.5433 in) |
| Mpn Variants | 7218B.TVP.P5, 7218BTVPP5, 7218 B TVP P5, 7218-B-TVP-P5, 7218B-TVP-P5 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Part Number | 7218B.TVP.P5 |
| Cross Reference 6 | Koyo 7218B P5 |
|---|---|
| Cross Reference 7 | 7218B.TVP |
A single-row angular contact ball bearing in the 72-series, 90 mm bore, 160 mm outside diameter, 30 mm width. It carries radial load together with axial load in one direction, and a pair mounted back-to-back or face-to-face handles axial load in both directions.
72 — ISO angular contact ball bearing dimension series18 — bore code, 18 × 5 = 90 mm boreB — 40° contact angle in the FAG 72xxB schemeTVP — one-piece machined glass-fibre reinforced polyamide 6.6 cage, ball-centredP5 — ISO dimensional and running accuracy class P5, equivalent to ABEC 5
A 40° contact angle is the high-thrust end of the standard angular contact range: it carries substantially more axial load than a 15° or 25° bearing of the same envelope, and runs at lower limiting speed with a stiffer axial response. The polyamide cage is light and quiet with good dry-running behaviour, and its continuous operating ceiling is approximately 120 °C, which sets the practical temperature limit of the assembly.
P5 accuracy tightens bore, outside diameter and running accuracy over standard P0 tolerances. It sits one class below P4 / ABEC 7 super-precision.
Single bearing, 1 Pc. A TVP.P5 bearing of this class is universally usable in pairs of the same designation for a duplex mount.
Angular contact bearings are directional: the wide shoulder of the outer ring takes the thrust, and the assembly seats against a square shaft shoulder and housing face. Mounting is by controlled interference on the shaft, with heating or a press applied to the ring that takes the fit.
Same-spec equivalents are 40° 7218B bearings at P5 accuracy from other makers: SKF 7218 BEP class P5, NSK 7218B P5, NTN 7218B P5, Koyo 7218B P5. A 7218 without the B suffix, or a 7218AC, carries a different contact angle and is a related size rather than an interchange. Standard-accuracy 7218B is the same envelope at looser tolerance.
