Fafnir | 2MM9111WISuper-Precision Spindle Angular Contact Ball Bearing - 55 mm ID, 90 mm OD, 18 mm Width, Open, 15° Contact Angle, ABEC 7/9$67.13
RHP | 7011TDULP4Super Precision Angular Contact Ball Bearing - 55 mm Bore, 90 mm OD, 18 mm Width, 15° Contact Angle, ABEC 7 / P4, Phenolic Cage$51.83
NHBB | ME-1111DLAngular Contact Bearing - 55 mm ID, 90 mm OD, 18 mm Width, Open, 15° Contact Angle$52.61
NDH | QOL11DTAngular Contact Ball Bearing - Straight Bore, 55 mm ID, 90 mm OD, 18 mm Width, Open.$55.22| MFR / Brand | Fafnir |
|---|---|
| MPN | 3MM9111WIC1 |
| Model | 3MM 9111 WI CR C1 / 7011 A5/AC TR/TY P4/P4Y |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 55 mm |
| OD | 90 mm |
| Width | 18 mm |
| Series | 9100 |
|---|---|
| Condition | New – Open box |
| Preload | Light |
| Material | Bearing Steel |
| Condition Note | Made In USA, New Old Stock |
| Closure Type | Open |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 43.6 kN / 9800 lbf |
| Static Load Rating | 32.5 kN / 7310 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Balls |
| Max Temp | 120 °C |
| Item Weight | 0.85 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mounting Arrangement | Single Universal |
| Limiting Speed | 15000 rpm |
| Cross Reference 1 | SKF 7011 CD/P4A |
|---|---|
| Cross Reference 2 | NSK 7011CTYNSULP4 |
| Cross Reference 3 | GMN S6011CTA |
Angular Contact Bearing – 55 mm ID, 90 mm OD, 18 mm Width, Open, 25° Contact Angle
