Availability:
1 in stock
Super precision angular contact ball bearing, 55 x 90 x 18 mm, 15 degree contact angle. ABEC 7 / P4 class, phenolic cage, universally ground faces for pairing.
List Price
$51.83
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | RHP |
|---|---|
| MPN | 7011CTSULP4 |
| Model | 7011 T DUL P4 / B7011 TA DUL EP7 / MM9111WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing |
| ID | 55 mm |
| OD | 90 mm |
| Width | 18 mm |
| Series | 7000 |
|---|---|
| Lubricant | Grease or oil |
| Preload | Light |
| Material | Bearing Steel |
| Base Number | 7011 |
| Industry Terms | Super precision bearing; spindle bearing; ABEC 7 bearing |
| Common Misspellings | 7011 C T SUL P4; 7011CSULP4; 7011 CTSULP4 |
| Application Types | Machine tool spindles; grinding spindles; motor spindles |
| Overall Width | 18 mm |
| Mpn Variants | 7011CTSULP4; 7011-C-T-SUL-P4; 7011TSULP4; B7011TADULEP7 |
| Precision Class | ABEC 7 / P4 |
| Closure Type | Open |
| Cage Type | Machined, outer-ring guided |
| Dynamic Load Rating | 34,000 N |
| Static Load Rating | 28,600 N |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 15,400 rpm grease; 25,000 rpm oil |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universally ground for pairing |
| Bearing Material | Bearing steel |
| Cross Reference 1 | SKF 7011 CD/P4A |
|---|---|
| Cross Reference 2 | FAG B7011-C-T-P4S |
| Cross Reference 3 | NSK 7011CTRSULP4 |
| Cross Reference 4 | NTN 7011UCG/GNP4 |
| Cross Reference 5 | Timken Fafnir 2MM9111WICRSUL |
| Cross Reference 6 | Koyo 7011C/GNP4 |
| Cross Reference 7 | NACHI 7011CYP4 |
| Cross Reference 8 | GMN S6011 C TA P4 |
| Cross Reference 9 | SNFA E 7011 7CE1 |
RHP 7011-C-T-SUL-P4 single-row super precision angular contact ball bearing. Bore Diameter: 55 mm. Outside Diameter: 90 mm. Overall Width: 18 mm. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Cage Material: Phenolic. Unit Quantity: 1 Pc.
70 — ISO dimension series 10, the light section of the RHP super precision angular contact range.
11 — bore code, 55 mm bore.
C — 15° contact angle, the low-angle option in the range.
T — machined laminated phenolic cage, outer-ring guided.
SU — universal face control. Faces are ground so that any two bearings from the range stack back-to-back, face-to-face or in tandem and reach the tabulated preload on clamping.
L — light preload class for a universal pair.
P4 — RHP tolerance class P4, equivalent to BS 292 EP7 and ABEC 7.
Dynamic Load Rating: 34,000 N. Static Load Rating: 28,600 N. Limiting Speed: 15,400 rpm grease; 25,000 rpm oil. Cage Type: Machined, outer-ring guided. Preload: Light. Mounting Arrangement: Universally ground for pairing. Item Weight: 0.375 kg (0.83 lb). Effective Load Centre a: 18.7 mm. Internal Free Volume: 16.9 cm3. Series: 7000. Harmonization Code: 8482.10.50. Country of Origin: United Kingdom.
Minimum inner ring abutment diameter: 62 mm. Maximum outer ring abutment diameter: 83 mm. Maximum outer ring seating diameter: 85 mm. Chamfer r min: 1.1 mm. Chamfer r1 min: 0.6 mm. Pitch circle diameter for lubrication jets: 67.3 mm.
The carton also carries the RHP B-series designation B7011TADULEP7 and the Fafnir equivalent MM9111WICRSUL. Equivalent 55 x 90 x 18 mm 15° super precision executions: SKF 7011 CD/P4A, FAG B7011-C-T-P4S, NSK 7011CTRSULP4, NTN 7011UCG/GNP4, Timken Fafnir 2MM9111WICRSUL, Koyo 7011C/GNP4, NACHI 7011CYP4, GMN S6011 C TA P4, SNFA E 7011 7CE1.
55 mm bore, 90 mm outside diameter and 18 mm width.
15°, from the C in the designation.
A single bearing with universally ground faces and light preload.
