This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Super Precision Angular Contact Ball Bearing - Straight Bore, 35 mm ID, 72 mm OD, 17 mm Width, Open, 25° Contact Angle, Light Preload, ABEC 7, Machined Phenolic Cage$93.21
Super Precision Angular Contact Ball Bearing Triplex Set - 35 mm ID, 72 mm OD, 17 mm Width, 51 mm Total, 25° Contact Angle, Light Preload$559.17
Double Row Angular Contact Ball Bearing - 35 mm ID, 72 mm OD, 27 mm Width, Open, C3 Internal Clearance$36.39
Angular Contact Ball Bearing - 35 mm ID, 72 mm OD, 17 mm Width, 40° Contact Angle, Bronze Cage, Counterbored Inner and Outer Rings, Universal Ground$41.51| MFR / Brand | Fafnir |
|---|---|
| MPN | 3MM207WIDUM |
| Model | 3MM 207 WI CR DUM / B 7207 E T DUM P4 / 7207A / 7207A5 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 35 mm |
| OD | 72 mm |
| Width | 17 mm |
| Material | Bearing Steel |
|---|---|
| Series | 3MM200 |
| Preload | Medium |
| Min Temp | -40 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 29 kN |
| Static Load Rating | 19 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 0.63 lbs |
| Cage Material | Phenolic Resin |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25 °C |
| Mounting Arrangement | Universal |
| Internal Clearance | CN |
| Limiting Speed | 17000 rpm |
| Cross Reference 1 | SKF 7207 ACD/P4ADGB |
|---|---|
| Cross Reference 2 | NSK 7207A5TYNDUMP4 |
| Cross Reference 3 | FAG B7207-E-T-P4S-DUM |
