This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 45 mm ID, 75 mm OD, 16 mm Width, Open, 15°, Medium Preload, Universal Duplex Pair Original price was: $266.14.$199.61Current price is: $199.61.
Super-Precision Angular Contact Ball Bearing - Straight Bore, Open, 25° Contact Angle, Phenolic Cage, ABEC 7, Medium Preload, Universally Matchable Pair Original price was: $171.50.$128.63Current price is: $128.63.
Angular Contact Ball Bearing - 45 mm ID, 75 mm OD, 16 mm Width, 15° Contact Angle, Open, ABEC 7/9 P4S$42.48
Super Precision Angular Contact Ball Bearing, Triplex Matched Set of 3, 45 x 75 x 16 mm, 15 Degree Contact Angle, Medium Preload, Phenolic Outer-Land-Riding Cage, ABEC 7/9 Original price was: $295.41.$221.56Current price is: $221.56.| MFR / Brand | Fafnir |
|---|---|
| MPN | 2MM9109WIDUM |
| Model | 2MM 9109 WI CR DUM / 7009 CD P4A DGB / 109 HC DUM |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 45 mm |
| OD | 75 mm |
| Width | 16 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Series | 9100 |
| Condition | New – Open box |
| Lubricant | Oil |
| Preload | Medium Preload |
| Condition Note | Made In USA, New Old Stock |
| Cage Type | Machined |
| Dynamic Load Rating | 29 kN / 6519 lbf |
| Static Load Rating | 24 kN / 5395 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Item Weight | 0.52 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 18000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Relubrication Feature | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Cross Reference 1 | SKF 7009 CD/P4ADGB |
|---|
Discover the Fafnir 2MM9109WI-DUM Bearing: your essential solution for precision and durability. This Angular Contact Ball Bearing is expertly designed for high-performance applications, ensuring smooth operation in various machinery and equipment. Engineered by the renowned brand FAFNIR, this bearing is a testament to quality and reliability. Key Features: Model: 2MM 9109 WI CR DUM / 7009 CD P4A DGB / 109 HC DUM Specifications: Bore Diameter: 45 mm Outside Diameter: 75 mm Width: 16 mm Condition: Brand New – Open Box Manufactured in: United States In addition, we understand the urgency of your needs. If you cannot find your part, do not hesitate to contact us! Our team can quickly source any part you require. Choose your shipping speed at checkout with options for next-day delivery and expedited shipping, plus we offer international shipping on all orders. We accept collect shipping with trusted carriers like UPS, FedEx, and DHL. At competitive prices, invest in the Fafnir 2MM9109WI-DUM Bearing for unmatched quality and performance. Order now and experience the difference!
