Fafnir2MM210WICRDULAngular Contact Ball Bearing — 50 mm ID, 90 mm OD, 20 mm Width, 15° Contact Angle, Light Preload, ABEC 7 / P4

Product Description

What this part is:

Fafnir 2MM210WICRDUL (Timken) is a super-precision angular contact ball bearing supplied as a matched duplex pair with Light preload. Unit Quantity: 2 Pcs. Series: 7200 (ISO 7210 size). Country of Origin: United States.

Decoding the designation:

2MM — Fafnir super-precision spindle bearing, 15° contact angle, ABEC 7 / ISO P4 tolerances.

210 — ISO 7210 envelope, 50 x 90 x 20 mm.

WI — low shoulder on both rings, the Fafnir duplex construction.

CR — phenolic cage.

DU — duplex universal: two bearings flush-ground as a matched set, mountable back-to-back, face-to-face or tandem.

L — Light preload.

Specifications:

Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 20 mm per bearing. Contact Angle: 15°. Number Of Rows: 1. Rolling Elements: Ball. Cage Material: Phenolic. Closure Type: Open. Preload: Light. Precision Class: ABEC 7 / P4. Dynamic Load Rating (C1): 47,400 N per bearing. Static Load Rating (C0): 31,700 N per bearing. Mounting Arrangement: Duplex universal (DU).

Compatibility and replacement:

SKF 7210 CD/P4ADGA (15°, P4, light preload universal pair). NSK 7210CTYNDULP4 (15°, P4, light preload pair, polyamide cage). FAG B7210-C-T-P4S-DUL (15°, light preload pair, P4S class). Part number variants: 2MM210WIDUL, 2MM210WICRDUL, 2MM 210 WI CR DUL, 7210CCRDULP4S, 7210-C-CR-DUL-P4S.

Frequently asked questions:

What are the dimensions of the Fafnir 2MM210WICRDUL?

Bore 50 mm, outside diameter 90 mm, width 20 mm per bearing.

What contact angle and precision class does 2MM mean?

2MM is a 15° contact angle with ABEC 7 / ISO P4 tolerances.

What does this listing include?

One matched duplex pair, 2 Pcs, with Light preload.
