Availability:
1 in stock
Barden 212HCRRDUL sealed angular contact ball bearing, 60 x 110 x 22 mm, 15° contact angle, phenolic cage, universal duplex ground with light preload.
List Price
$152.80
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Barden |
|---|---|
| MPN | 212HCRRDUL |
| Model | 212WI DUL |
| Bearing Type | Angular Contact Ball Bearing, Seals both sides (RR) |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Mpn Variants | 212HCRRDUL, 212 HCRRDUL, 212HCRRUL, 212 HC RR DUL |
|---|---|
| Compatible With Replaces | Barden 212HC family (sealed RR execution) |
| Additional Attributes | Radius r1 max: 1.50 mm; Radius r2 max (non-thrust side): 0.76 mm |
| Cage Type | Outer-ring centred |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Contact Angle | 15° |
| Preload | Light |
| Mounting Arrangement | Universal duplex (DB, DF or DT) |
| Cross Reference 1 | FAG B7212-C-T-P4S-UL (open) |
|---|---|
| Cross Reference 2 | SKF 7212 CD/P4A (open) |
| Cross Reference 3 | NSK 7212CTRSULP4 (open) |
| Cross Reference 4 | Fafnir 2MM212WI SUL (open) |
Barden 212HCRRDUL is a sealed super precision angular contact ball bearing in the ISO 7212 envelope, ground for universal duplex mounting at light preload. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Contact Angle: 15°.
212 — Barden 200-series bore code 12, 60 mm bore, ISO 72 dimension series.
H — textile laminated phenolic resin cage, outer ring centred.
C — 15° contact angle.
RR — sealed execution, seals on both sides.
DU — universal duplex matching; mounts back-to-back, face-to-face or tandem with another DU bearing.
L — light preload.
Cage Material: Phenolic. Cage Type: Outer-ring centred. Closure Type: Seals both sides. Preload: Light. The 15° angle favours speed and radial stiffness in spindle service.
Radius r1 max: 1.50 mm. Radius r2 max, non-thrust side: 0.76 mm.
Unit Quantity: 1 Pc, a single universal duplex bearing.
Open same-envelope 15° equivalents: FAG B7212-C-T-P4S-UL, SKF 7212 CD/P4A, NSK 7212CTRSULP4, Fafnir 2MM212WI SUL.
