Angular Contact Spindle Bearing — 80 mm ID, 125 mm OD, 22 mm Width, 15°, Light Preload, P4S, Phenolic Cage$289.04| MFR / Brand | RHP |
|---|---|
| MPN | 7016TDULP4 |
| Model | 7016 T DUL P4 / MM9116WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 80 mm |
| OD | 125 mm |
| Width | 22 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Preload | Light |
| Min Temp | -40°C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 54 kN |
| Static Load Rating | 51 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120°C |
| Item Weight | 1.80 lbs |
| Cage Material | Phenolic Resin |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Internal Clearance | CN |
| Limiting Speed | 13000 rpm |
| Cross Reference 1 | SKF 7016 CD/P4A |
|---|---|
| Cross Reference 2 | FAG B7016-C-T-P4S |
| Cross Reference 3 | NSK 7016CTYNSULP4 |
