Availability:
Out of stock
Super-precision angular contact ball bearing, 50 x 80 x 16 mm, 15° contact angle, light preload, ISO P4 tolerances, phenolic cage, straight bore.
List Price
$120.25
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - Straight Bore, 50 mm ID, 80 mm OD, 16 mm Width, Open, 15° Contact Angle, Light Preload.$102.90
Super Precision Angular Contact Ball Bearing Matched Duplex Pair 50 x 80 x 16 mm 15 Degree ABEC 7 Light Preload$204.40
Angular Contact Ball Bearing - Straight Bore, 50 mm ID, 80 mm OD, 16 mm Width, Open, 25° Contact Angle, Light Preload.$203.77
Super-Precision Angular Contact Ball Bearing Duplex Pair - 50 mm ID, 80 mm OD, 16 mm Width, 32 mm Pair Width, Open, 15° Contact Angle, Light Preload, P4S$68.82| MFR / Brand | SNR |
|---|---|
| MPN | 7010CVDUJ74 |
| Model | 7010C T DUL P4 / 2MM9110WI CR DUL / 7010 C V DU J74 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 50 mm |
| OD | 80 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Preload | Light |
| Base Number | 7010 |
| Bore Shaft Size | 50 mm |
| Mpn Variants | 7010-C-V-DU-J74; 7010 C V DU J74; 7010CDUJ74; 7010C; 7010C-T-DUL-P4; 2MM9110WI CR DUL |
| Precision Class | ISO P4 (ABEC 7) |
| Precision Rating | ISO P4 (ABEC 7) |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.68 |
| Contact Angle | 15° |
| Part Number | 7010CVDUJ74 |
SNR 7010CVDUJ74 super-precision angular contact ball bearing, ISO 70 series, 50 x 80 x 16 mm. Brand: SNR. Manufacturer Part Number: 7010CVDUJ74. Bearing Type: Angular contact ball bearing. Bore: 50 mm. Outside Diameter: 80 mm. Overall Width: 16 mm. Bore Type: Straight. Number Of Rows: 1. Rolling Elements: Ball. Closure Type: Open.
Contact Angle: 15°, carried by the C in 7010C. Preload: Light, carried by the J74 code. Precision Class: ISO P4, equivalent to ABEC 7. Cage Material: Phenolic. Series: 7000. Searchable forms of the designation: 7010CVDUJ74, 7010-C-V-DU-J74, 7010 C V DU J74, 7010C.
A 15° contact angle favours speed and radial rigidity over thrust capacity, which suits a machine-tool spindle position. Light preload keeps the ball complement in contact under a modest set force, giving repeatable running accuracy with low heat generation. ISO P4 holds tighter bore, outside diameter and running accuracy than standard class, locating the shaft more closely and running with less vibration. The phenolic cage is light and quiet at speed.
New old stock, French manufacture, with grease staining on the rings from storage.
Unit Quantity: 2 Pcs. Universally ground rings, matchable so the two bearings set together at the stated preload.
Cross-Reference 1: SKF 7010 CD/P4ADGA. Cross-Reference 2: FAG B7010-C-T-P4S-DUL. Cross-Reference 3: NSK 7010CTYNDULP4. Fafnir carton equivalent: 2MM9110WI CR DUL. A same-envelope bearing at a different contact angle is a related size rather than a substitution.
