Angular Contact Ball Bearing - 50 mm ID, 80 mm OD, 16 mm Width, Open, 25°, Heavy Preload, Universal Duplex Pair$224.42
Super-Precision Angular Contact Ball Bearing 50x80x16 mm, 15 Degree Contact Angle, Light Preload, Phenolic Cage, Matched Pair$89.90
Angular Contact Ball Bearing - 50 mm ID, 80 mm OD, 16 mm Width, 15° Contact Angle, P4, Heavy Preload, Phenolic Cage$263.93
Angular Contact Ball Bearing — 50 mm ID, 80 mm OD, 16 mm Width, 15° Contact Angle, ABEC 7, PEEK Cage, Universal Light Preload$47.53| MFR / Brand | Fafnir |
|---|---|
| MPN | 3MM9110WICRDUH |
| Model | 7010A5 T DUH P4 / 3 MM 9110 WI CR DUH / 7010A / 7010AC / B7010E |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 50 mm |
| OD | 80 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 9100 |
| Lubricant | Oil |
| Preload | Heavy |
| Min Temp | -30°C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 32.5 kN |
| Static Load Rating | 28 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120°C |
| Item Weight | 1.10 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 25° |
| Mounting Arrangement | Universal |
| Limiting Speed | 20000 rpm |
| Cross Reference 1 | SKF 71910 ACD/P4DGC |
|---|---|
| Cross Reference 2 | NSK 7910A5TYNDUHP4 |
