GE-FanucIC600LX624Series Six Combined Memory Module, 16K Logic, 8K Register

Product Description

What this part is:

GE Fanuc IC600LX624 is a Combined Memory Module for the Series Six and Series Six Plus programmable controller. It holds the PLC’s user program and data. One module carries logic (user ladder program) memory, register memory and internal memory. Unit Quantity: 1 Pc.

Decoding the designation:

IC600 — GE Fanuc Series Six / Series Six Plus product family.

LX — memory module, the combined logic and register board.

624 — capacity variant: 16K words of logic memory and 8K words of register memory.

Trailing letter (IC600LX624L, -A through -Z) — hardware revision level of the same capacity.

Specifications:

Logic Memory: 16K words. Register Memory: 8K words. Internal Memory: on the same board. Word Length: 16 bits. Memory Technology: CMOS static RAM, battery-backed, with on-board voltage-level detection circuitry. Backup Battery: lithium manganese dioxide, on the main circuit board. Power Required: +5 V DC at 1.5 A max and -12 V DC at 10 mA max from the rack CPU power supply. Compatible Platforms: Series Six (Model 60, 600, 6000) and Series Six Plus. Type: Circuit Board. Part Number: IC600LX624.

Dimensions and mounting:

Mounting Type: rack slot 4 on the Series Six CPU rack backplane, immediately to the left of the Arithmetic Control module. Connector: Series Six backplane connectors. Assembly Type: static-sensitive circuit board with the memory-protect setting carried on the board.

Compatibility and replacement:

IC600LX624A through IC600LX624Z are the same catalogue item at different hardware revisions. Other IC600LX numbers are different capacities. Related items on the same platform: IC600CP624 19-inch 11-slot CPU rack, IC600CB516 and IC600CB536 Communications Control Modules, and Series Six I/O boards in the IC600BF and IC600YB ranges. Also searched as IC600-LX624, IC600 LX 624, LX624 and GE Series 6 memory board.

Frequently asked questions:

What is the GE Fanuc IC600LX624?

A Combined Memory Module for the Series Six and Series Six Plus PLC, carrying 16K words of logic memory and 8K words of register memory in battery-backed CMOS RAM.

Where does the IC600LX624 mount?

Rack slot 4 on the Series Six CPU rack backplane, immediately to the left of the Arithmetic Control module.

Which platforms use the IC600LX624?

Series Six (Model 60, 600, 6000) and Series Six Plus.
