Name: Deep Groove Ball Bearing - Straight Bore, 15mm ID, 24mm OD, 5mm Width, Double Shielded, Thin Section 8 pcs
Brand: NSK
SKU: AR4B2#I5WIDO
Price: 53.47 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	NSK
MPN	6802ZZ
Model	6802 Z
Bearing Type	Deep Groove Ball Bearing, Double Shield
ID	15mm
OD	24mm
Width	5mm

Specifications

Advertise	1
Series	6800
Condition	New – Open box
Lubricant	Grease
Material	Bearing Steel
Min Temp	-30°C
Cage Type	Ribbon
Dynamic Load Rating	2.08 kN / 468 lbf
Static Load Rating	1.26 kN / 283 lbf
Precision Rating	ABEC 1 / P0
Rolling Elements	Balls
Max Temp	120°C
Item Weight	0.02 lbs
Cage Material	Steel
Limiting Speed	28000 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Internal Clearance	CN

Cross-References

Cross Reference 1	SKF 61802-2Z
Cross Reference 2	FAG 61802-2Z
Cross Reference 3	NTN 6802ZZ
Cross Reference 4	Timken 6802-ZZ
Cross Reference 5	Koyo 6802ZZ
