Availability:
3 in stock
Tapered roller bearing single cup, 13.2500 in outer diameter, 2.1250 in width. Case-carburized steel, straight OD, e factor 0.5 for opposed-pair mounting.
List Price
$595.39
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Timken |
|---|---|
| MPN | 591326 |
| Model | 591326 |
| Bearing Type | Tapered Roller Bearing Cup |
| OD | 13.2500 in (336.550 mm) |
| Material | Steel |
|---|---|
| Series | 590000 |
| Base Number | 591326 |
| Industry Terms | taper bearing cup, bearing race, outer ring, TS cup, tapered roller bearing race |
| Overall Width | 2.1250 in (53.975 mm) |
| Mpn Variants | 591326, 591-326, 591 326 |
| Precision Class | Not specified |
| Additional Attributes | e Factor 0.5; Geometry Factor (Cg) 0.129; Max Housing Fillet Radius 0.250 in (6.35 mm); Housing Backing Shoulder Dia. Frontface (Da) 12.12 in (307.85 mm); Housing Backing Shoulder Dia. Backface (Db) 11.65 in (295.91 mm) |
| Item Weight | 64.5 lb (29.200 kg) |
| Number Of Rows | 1 |
| Harmonization Code | 8482.20.00 |
| Cup Part Number | 591326 |
| Design Units | Imperial |
| Bearing Class | Not specified |
| Bearing Material | Case-Carburized Steel |
| Cup Width | 2.1250 in (53.975 mm) |
| Cup Backface To Clear Radius | 0.25 in |
| Part Number | 591326 |
| Cup Frontface Backing Diameter | 12.44 in |
| Cross Reference 1 | Timken 591326 |
|---|
Timken 591326 tapered roller bearing single cup. Series: 590000. Outside Diameter: 13.2500 in (336.550 mm). Outer Ring Width: 2.1250 in (53.975 mm). Straight outside diameter, case-carburized steel. Design Units: Imperial. Country of Origin: United States.
591326 is the Timken cup part number in the 590000 inch series. Searchable forms: 591326, 591-326, 591 326.
e Factor: 0.5. The e factor is the thrust-to-radial load ratio at which the bearing calculation changes to its combined-load form, so a higher e value carries a larger share of thrust before that shift. Geometry Factor (Cg): 0.129, the geometry constant used in the lubrication life adjustment factor a3l. Case-carburized steel gives a hard raceway over a tough core, which suits shock loading and heavy press fits.
Maximum housing fillet radius: 0.250 in (6.35 mm). Housing backing shoulder diameter, frontface (Da): 12.12 in (307.85 mm). Housing backing shoulder diameter, backface (Db): 11.65 in (295.91 mm). Weight: 64.5 lb (29.200 kg).
Cup only. Unit Quantity: 1 Pc. Number of rows: 1.
591326 is the Timken cup designation and is ordered under that number across the trade. Cup and cone are a matched raceway pair, and the cup carries the outer raceway angle of that pair.
