FAG22232-E1-C3Spherical Roller Bearing – 160 mm ID, 290 mm OD, 80 mm Width, Straight Bore, W33, C3 Clearance

Product Description

What this part is:

FAG 22232-E1-C3 double-row spherical roller bearing with a straight bore, E1 reinforced design, C3 internal clearance and a W33 lubrication groove with three radial holes in the outer ring. Unit Quantity: 1 Pc.

Decoding the designation:

222 — double-row spherical roller bearing series to DIN 635-2.

32 — bore code, multiplied by five: 160 mm.

E1 — reinforced design with an enlarged roller complement.

C3 — internal clearance greater than normal.

W33 — annular groove in the outer ring outside diameter with three radial holes through to the rolling elements. Groove width 15 mm, hole diameter 8 mm. Lubricant: grease or oil.

Specifications:

Bore Diameter: 160 mm. Outside Diameter: 290 mm. Overall Width: 80 mm. Number Of Rows: 2. Rolling Elements: Spherical Roller. Bore Type: Straight. Closure Type: Open. Dynamic Load Rating: 1,150,000 N. Static Load Rating: 1,400,000 N. Fatigue Load Limit: 129,000 N radial. Limiting Speed: 2,650 rpm. Reference Speed: 1,900 rpm. Internal Clearance: C3. Operating temperature: -30 °C to +200 °C. Item Weight: 22.52 kg (49.64 lb). Bearing Material: Chrome steel. Series: 222. Base Number: 22232. Dynamic axial load factor: 3.93. Static axial load factor: 2.58. Factor change at Fa/Fr: 0.26.

Dimensions and mounting:

Minimum shaft shoulder diameter: 174 mm. Maximum housing shoulder diameter: 276 mm. Outer ring bore diameter: 258.2 mm. Inner ring raceway diameter: 190.9 mm. Minimum chamfer dimension: 3 mm. Maximum housing recess radius: 2.5 mm.

Compatibility and replacement:

Cross-Reference 1: SKF 22232 CC/C3W33 – 1,043 kN dynamic vs 1,150 kN. Schaeffler lists 22232-E1-XL-C3 as the current designation that replaces 22232-E1-C3 and 22232E1.C3.

Frequently asked questions:

What are the dimensions of the FAG 22232-E1-C3?

Bore 160 mm, outside diameter 290 mm, width 80 mm.

What load ratings does it have?

Dynamic Load Rating 1,150,000 N and Static Load Rating 1,400,000 N. Limiting Speed 2,650 rpm.

What do E1, C3 and W33 mean?

E1 is the reinforced design, C3 is internal clearance greater than normal, and W33 is an outer ring groove with three radial holes for grease or oil.
