SKF6006-2RSJEMDeep Groove Ball Bearing – 30 mm Bore, 55 mm OD, 13 mm Width, Contact Seals Both Sides, C3 Clearance, Steel Cage

Product Description

What this part is: SKF 6006-2RSJEM is a single-row deep groove ball bearing with contact seals on both sides and C3 internal clearance. Bore Diameter: 30 mm. Outside Diameter: 55 mm. Overall Width: 13 mm. Closure Type: Contact seals both sides. Internal Clearance: C3. Cage Material: Pressed steel. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Bearing Material: Chrome steel. Lubricant: Grease or oil. Series: 60. Base Number: 6006. Unit Quantity: 4 Pcs. GTIN: 7316576617799. Decoding the designation: 6006 — ISO 60 dimension series at a 30 mm bore, giving a 30 x 55 x 13 mm envelope. 2RS — contact seals on both sides, anchored in the outer ring and running against the inner ring shoulder. J — pressed steel cage. EM — SKF’s carton marking for the C3 internal clearance, quiet-running execution. The ring itself is marked C3. What these specs mean in practice: Dynamic Load Rating: 13,800 N. Static Load Rating: 8,300 N. Limiting Speed: 8,000 rpm grease. C3 clearance is greater than normal, which keeps running clearance positive where the inner ring runs hotter than the housing or where the shaft fit is tight. Contact seals hold the grease charge in and keep contamination out, so the bearing runs as supplied with no relubrication path. The steel cage and the sealed grease fill are what set the 8,000 rpm ceiling. Mounting data: Bore Diameter: 30 mm. Outside Diameter: 55 mm. Overall Width: 13 mm. The seals sit within the ring width, so the bearing fits a plain 13 mm housing counterbore with no extra axial allowance. Quantity and configuration: Unit Quantity: 4 Pcs. Four individual bearings, each complete and sealed. Interchange guidance: The same bearing is written 6006-2RSJEM, 6006 2RSJEM, 6006-2RS-C3 and 6006RS. Cross-Reference 1: SKF 6006-2RSH/C3. Cross-Reference 2: FAG 6006-2RSR-C3. Cross-Reference 3: NSK 6006DDUC3. Cross-Reference 4: NTN 6006LLUC3. Cross-Reference 5: Koyo 6006-2RSC3. Cross-Reference 6: Timken 6006-2RSC3. Cross-Reference 7: INA 6006-2RSR-C3. Cross-Reference 8: Nachi 6006-2NSE-C3. Cross-Reference 9: NTN-SNR 6006EEC3. Every number above shares the 30 x 55 x 13 mm envelope, contact seals on both faces and C3 clearance. The shielded form of the same size is written 6006-2Z and the open form 6006; both fit the same shaft and housing and change the closure, so they are related sizes.
