Availability:
1 in stock
Deep groove ball bearing, 85 x 150 x 28 mm, steel shields both sides, C3 clearance. Cr 92,500 N, C0r 62,000 N, 4,800 rpm limiting speed on grease.
List Price
$45.88
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 6217ZZC3 |
| GTIN | 029176015687 |
| Model | 6217ZZ C3 E |
| Bearing Type | Ball Bearing, Double Shield |
| ID | 85 mm |
| OD | 150 mm |
| Width | 28 mm |
| Series | 6200 |
|---|---|
| Lubricant | Grease |
| Material | Chrome Steel |
| Industry Terms | Deep groove ball bearing, shielded bearing, radial ball bearing, 6200 series, C3 clearance |
| Overall Width | 28 mm |
| Mpn Variants | 6217ZZC3, 6217ZZ C3 E, 6217 ZZ C3, 6217ZZC3E, 6217Z, 6217ZZ, 6217-2Z/C3 |
| Precision Class | ISO Normal class |
| Additional Attributes | Balls: 10 x 20.638 mm; da 94-102 mm; Da max 141 mm; ra max 2 mm; r min 2 mm; fo 14.5 |
| Cage Type | Pressed cage |
| Dynamic Load Rating | 92,500 N (Cr) |
| Static Load Rating | 62,000 N (C0r) |
| Rolling Elements | Ball |
| Item Weight | 1.76 kg (3.88 lb) |
| Cage Material | Pressed steel |
| Limiting Speed | 4,800 rpm grease |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Internal Clearance | C3 |
| Harmonization Code | 84821000 |
| Bearing Material | Chrome steel |
| Cross Reference 1 | SKF 6217-2Z/C3 |
|---|---|
| Cross Reference 2 | FAG 6217-2Z-C3 |
| Cross Reference 3 | NTN 6217ZZC3 |
| Cross Reference 4 | Koyo 6217ZZC3 |
| Cross Reference 5 | Nachi 6217ZZC3 |
| Cross Reference 6 | SNR 6217.ZZ.J30 |
NSK 6217ZZC3 single-row deep groove ball bearing with a steel shield on each side and C3 radial internal clearance. Bore Diameter: 85 mm. Outside Diameter: 150 mm. Overall Width: 28 mm. Unit Quantity: 1 Pc.
6217 — ISO 6217 size, light series 62, 85 x 150 x 28 mm.
ZZ — steel shields both sides.
C3 — radial internal clearance greater than normal.
Dynamic Load Rating: 92,500 N (Cr). Static Load Rating: 62,000 N (C0r). Limiting Speed: 4,800 rpm on grease. Closure Type: Shields both sides. Internal Clearance: C3. Cage Material: Pressed steel. Precision Class: ISO Normal. Rolling Elements: 10 balls, 20.638 mm diameter. Number Of Rows: 1. Bore Type: Straight. Bearing Material: Chrome steel. Lubricant: Grease. Item Weight: 1.76 kg (3.88 lb). Snap Ring Included: No. Harmonization Code: 84821000. Country of Origin: Japan.
Shaft Abutment Diameter da: 94 mm minimum, 102 mm maximum. Housing Abutment Diameter Da max: 141 mm. Maximum Shaft or Housing Fillet Radius ra max: 2 mm. Ring Chamfer r min: 2 mm. Calculation factor fo: 14.5.
Cross-references: SKF 6217-2Z/C3, FAG 6217-2Z-C3, NTN 6217ZZC3, Koyo 6217ZZC3, Nachi 6217ZZC3, SNR 6217.ZZ.J30. Each shares the 85 x 150 x 28 mm envelope, shields on both sides and C3 clearance.
Bore 85 mm, outside diameter 150 mm, width 28 mm.
ZZ is a steel shield on both sides; C3 is radial internal clearance greater than normal.
Dynamic load rating 92,500 N, static load rating 62,000 N, limiting speed 4,800 rpm on grease (NSK datasheet).
