Availability:
1 in stock
NSK 6215ZZC3 deep groove ball bearing, 75 x 130 x 25 mm, steel shields both sides, C3 clearance. Dynamic load rating 73,000 N, grease speed 4,800 rpm.
List Price
$38.17
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 6215ZZC3 |
| Model | 6215ZZ |
| Bearing Type | Ball Bearing |
| ID | 75 mm |
| OD | 130 mm |
| Width | 25 mm |
| Mpn Variants | 6215ZZC3, 6215ZZ C3, 6215-ZZ-C3, 6215ZZ, 6215Z, 6215-2Z C3 |
|---|---|
| Dynamic Load Rating | 73,000 N |
| Static Load Rating | 49,500 N |
| Series | 6200 |
| Rolling Elements | Ball |
| Type | Deep Groove Ball Bearing |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Limiting Speed | 4,800 rpm grease |
| Internal Clearance | C3 |
| Lubricant | Grease |
| Cross Reference 1 | SKF 6215-2Z/C3 |
|---|---|
| Cross Reference 2 | FAG 6215-2Z-C3 |
| Cross Reference 3 | NTN 6215ZZC3 |
| Cross Reference 4 | Koyo 6215ZZC3 |
NSK 6215ZZC3 single-row deep groove ball bearing, 75 mm bore, 130 mm outside diameter, 25 mm width, with steel shields on both sides and C3 internal clearance.
62 — deep groove ball bearing, ISO dimension series 02.
15 — bore code, 15 x 5 = 75 mm bore.
ZZ — NSK steel shields on both sides, pre-greased.
C3 — radial internal clearance greater than normal, for running with a tight shaft fit or higher operating temperature.
Bore Diameter: 75 mm. Outside Diameter: 130 mm. Overall Width: 25 mm. Dynamic Load Rating: 73,000 N. Static Load Rating: 49,500 N. Limiting Speed: 4,800 rpm grease. Closure Type: Shields both sides. Internal Clearance: C3. Cage Material: Pressed steel. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Lubricant: Grease. Unit Quantity: 1 Pc.
Envelope 75 x 130 x 25 mm, ISO 6215 size. Straight bore.
Interchanges with SKF 6215-2Z/C3, FAG 6215-2Z-C3, NTN 6215ZZC3, Koyo 6215ZZC3 and MRC 215SFF with C3 fit.
CAD model and data sheet: available from NSK (oss.nsk.com).
What size is the NSK 6215ZZC3?
75 mm bore, 130 mm outside diameter, 25 mm width.
Is it sealed or shielded?
Shielded. ZZ is two steel shields, one on each side.
What does C3 mean?
Radial internal clearance one step greater than normal.
