Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
2 in stock
Sealed deep groove ball bearing, 70 x 125 x 24 mm, rubber contact seals both sides. MRC 214SZZ, the 6214-2RS envelope, single row, grease filled, CN clearance.
List Price
$40.71
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | MRC |
|---|---|
| MPN | 214SZZ |
| Model | 214 SZZ |
| Bearing Type | Ball Bearing, Double Rubber Seal |
| ID | 70 mm |
| OD | 125 mm |
| Width | 24 mm |
| Material | Bearing Steel |
|---|---|
| Dynamic Load Rating | 63,700 N |
| Static Load Rating | 45,000 N |
| Rolling Elements | Ball |
| Item Weight | 1.09 kg (2.41 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.68 |
| Limiting Speed | 3,400 rpm grease |
| Base Number | 6214 |
| Industry Terms | Deep groove ball bearing; sealed ball bearing; radial ball bearing; single row ball bearing; 2RS ball bearing |
| Common Misspellings | 214SZ; 214 S ZZ; 214ZZS; MRC214SZZ; 6214 2RS |
| Total Width | 24 mm |
| Overall Width | 24 mm |
| Bore Shaft Size | 70 mm |
| Mpn Variants | 214SZZ; 214 SZZ; 214-SZZ |
| Compatible With Replaces | SKF 6214-2RS1 (current SKF equivalent) |
| Internal Clearance | CN |
| Lubricant | Grease |
| Design Units | Metric |
| Bearing Material | Bearing steel |
| Part Number | 214SZZ |
| Application Types | Electric motors; pumps; gearboxes; industrial machinery; conveyors |
| Cross Reference 1 | SKF 6214-2RS1 |
|---|---|
| Cross Reference 2 | FAG 6214-2RSR |
| Cross Reference 3 | NSK 6214DDU |
| Cross Reference 4 | NTN 6214LLU |
| Cross Reference 5 | Koyo 6214-2RS |
| Cross Reference 6 | Fafnir 214PP |
MRC 214SZZ single-row deep groove ball bearing with a rubber contact seal on each face. Bore Diameter: 70 mm. Outside Diameter: 125 mm. Overall Width: 24 mm. Rolling Elements: Ball. Number Of Rows: 1. Closure Type: Contact seals both sides. Internal Clearance: CN. Unit Quantity: 1 Pc.
214 — MRC 200-series bore code, 70 mm bore, ISO 6214 boundary dimensions.
S — Conrad-assembly single-row deep groove construction.
ZZ — two rubber seals, one on each face. On MRC this code is an elastomer seal, not a metal shield.
Successor SKF 6214-2RS1 data: Dynamic Load Rating: 63,700 N. Static Load Rating: 45,000 N. Limiting Speed: 3,400 rpm grease. Lubricant: Grease. Cage Material: Pressed steel. Bearing Material: Bearing steel. Item Weight: 1.09 kg (2.41 lb).
Bore Diameter: 70 mm, cylindrical bore. Outside Diameter: 125 mm. Overall Width: 24 mm. Base Number: 6214.
Cross-references: SKF 6214-2RS1 (current SKF equivalent), FAG 6214-2RSR, NSK 6214DDU, NTN 6214LLU, Koyo 6214-2RS, Fafnir 214PP. All are sealed 70 x 125 x 24 mm deep groove bearings.
Carton and search variants: 214 SZZ, 214-SZZ, 6214RS.
70 mm bore, 125 mm outside diameter, 24 mm width.
Two rubber contact seals, one on each face, not metal shields.
SKF 6214-2RS1.
