Availability:
1 in stock
FAG 6210-2RSR-C3 deep groove ball bearing, 50 mm bore x 90 mm OD x 20 mm wide, rubber seals both sides, C3 clearance, 39,000 N dynamic rating. Set of 2.
List Price
$42.08
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 6210-2RSR-C3 |
| Model | 6210.2RSR.C3 |
| Bearing Type | Ball Bearing, Contact rubber seals both sides (2RSR) |
| ID | 50 mm |
| OD | 90 mm |
| Width | 20 mm |
| Series | 6200 |
|---|---|
| Cage Type | Sheet metal cage |
| Dynamic Load Rating | 39,000 N |
| Static Load Rating | 24,200 N |
| Rolling Elements | Ball |
| Max Temp | 100 °C |
| Item Weight | 0.461 kg (1.02 lb) per bearing |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 4,300 rpm grease |
| Internal Clearance | C3 |
| Base Number | 6210 |
| Industry Terms | deep groove ball bearing, sealed ball bearing, 6200 series, C3 clearance |
| Common Misspellings | 6210 2RSR C3, 6210RSRC3, 6210-2RSC3 |
| Application Types | electric motors, pumps, gearboxes, fans, conveyors |
| Mpn Variants | 6210-2RSR-C3, 6210.2RSR.C3, 6210.2RSR.T.C3, 62102RSRC3, 62102RSC3, 6210-2RS-C3 |
| Additional Attributes | Fatigue load limit 1,460 N; min shaft shoulder 57 mm; max housing shoulder 83 mm; max fillet radius 1 mm |
| Min Temp | -20 °C |
| Cross Reference 1 | SKF 6210-2RS1/C3 |
|---|---|
| Cross Reference 2 | NSK 6210DDUC3 |
| Cross Reference 3 | NTN 6210LLUC3 |
| Cross Reference 4 | Koyo 6210-2RSC3 |
FAG 6210-2RSR-C3 single-row deep groove ball bearing with contact rubber seals on both sides and C3 internal clearance, 50 mm bore, 90 mm outside diameter, 20 mm width, pressed steel cage. Unit Quantity: 2 Pcs. Condition: new.
6210 — 62 series (light section) deep groove ball bearing; bore code 10 × 5 = 50 mm bore.
2RSR — contact lip seals of rubber on both sides.
C3 — radial internal clearance greater than normal.
Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 20 mm. Series: 6200. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Cage Material: Pressed steel. Closure Type: Contact seals both sides. Internal Clearance: C3. Dynamic Load Rating: 39,000 N. Static Load Rating: 24,200 N. Limiting Speed: 4,300 rpm. Fatigue Load Limit: 1,460 N. Item Weight: 0.461 kg (1.02 lb) per bearing. Operating Temperature: −20 °C to 100 °C.
Minimum shaft shoulder diameter: 57 mm. Maximum housing shoulder diameter: 83 mm. Maximum fillet radius: 1 mm. Minimum chamfer dimension: 1.1 mm.
Same 50 x 90 x 20 mm envelope, sealed, C3: SKF 6210-2RS1/C3, NSK 6210DDUC3, NTN 6210LLUC3, Koyo 6210-2RSC3. Other forms of this number: 6210-2RSR-C3, 6210.2RSR.C3, 6210.2RSR.T.C3, 62102RSRC3 and 6210-2RS-C3.
Bore 50 mm, outside diameter 90 mm, width 20 mm.
2RSR is contact rubber lip seals on both sides; C3 is radial internal clearance greater than normal.
Dynamic Load Rating: 39,000 N. Static Load Rating: 24,200 N. Limiting Speed: 4,300 rpm.
