SNFA VEX12-9CE0 high-speed angular contact ball bearing, 12 x 28 x 8 mm, 12° contact angle, ABEC 9 / P2, phenolic cage. ISO size 7001. Two pieces.
List Price
$129.98
7 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | VEX12-9CE0 |
| Model | VEX12-9-CE-0 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 12 mm |
| OD | 28 mm |
| Width | 8 mm |
| Series | SNFA VEX (ISO 10) |
|---|---|
| Closure Type | Open |
| Cage Type | Outer-ring located |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 12° |
| Base Number | 7001 |
| Overall Width | 8 mm |
| Mpn Variants | VEX12-9CE0, VEX12-9-CE-0, VEX 12 9 CE 0, VEX12 9CE0, 7001-P2 |
| Precision Class | ABEC 9 / P2 |
| Additional Attributes | Minimum chamfer Rmin 0.3 mm; rmin 0.15 mm |
SNFA VEX12-9CE0 is a high-speed super-precision angular contact ball bearing from the SNFA VEX series, ISO dimension series 10, size 7001. Unit Quantity: 2 Pcs. Condition: New.
VEX — SNFA high-speed series, ISO dimension series 10.
12 — bore diameter, 12 mm.
9 — ABEC 9 precision.
C — stratified textile resin (phenolic) cage.
E — cage located on the outer ring.
0 — 12° nominal contact angle.
Bearing Type: Angular Contact Ball Bearing. Rolling Elements: Ball. Contact Angle: 12°. Precision Class: ABEC 9 / P2. Cage Material: Phenolic. Cage Type: Outer-ring located. Closure Type: Open. Bore Type: Straight. Snap Ring: No.
Bore Diameter: 12 mm. Outside Diameter: 28 mm. Overall Width: 8 mm. Minimum chamfer, outer ring (Rmin): 0.3 mm. Minimum chamfer, inner ring (rmin): 0.15 mm.
ISO size 7001, 12 x 28 x 8 mm. MPN Variants: VEX12-9CE0, VEX12-9-CE-0, VEX 12 9 CE 0, VEX12 9CE0, 7001-P2.
Bore Diameter is 12 mm, Outside Diameter is 28 mm and Overall Width is 8 mm, ISO size 7001.
Contact Angle is 12° (code 0) and Precision Class is ABEC 9 / P2 (code 9).
C is a stratified textile resin (phenolic) cage and E means the cage is located on the outer ring.
