Single-row angular contact ball bearing, 60 x 110 x 22 mm, 40° contact angle, open, straight bore, one-piece glass-fibre polyamide window cage.
List Price
$52.12
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SLF |
|---|---|
| MPN | 7212B.TVP |
| GTIN | 4035804160298 |
| Model | 7212 B TVP |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Material | Chrome steel |
|---|---|
| Series | 72 |
| Lubricant | Grease or oil |
| Base Number | 7212 |
| Common Misspellings | 7212 BTVP, 7212B TVP, 7212B-TVP, 7212BTV, SLF 7212BTVP, SFL 7212B.TVP |
| Overall Width | 22 mm |
| Bore Shaft Size | 60 mm |
| Mpn Variants | 7212B.TVP, 7212BTVP, 7212-B-TVP, 7212 B TVP, 7212B |
| Additional Attributes | Boundary dimensions to DIN 628-1 |
| Cage Type | One-piece window cage |
| Rolling Elements | Ball |
| Cage Material | Polyamide |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Contact Angle | 40° |
| Mounting Arrangement | Single |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Part Number | 7212-B-TVP |
| Cross Reference 1 | FAG 7212-B-TVP |
|---|---|
| Cross Reference 2 | FAG 7212-B-XL-TVP (related, X-life) |
| Cross Reference 3 | SKF 7212 BECBP |
| Cross Reference 4 | NSK 7212B |
| Cross Reference 5 | NTN 7212B |
| Cross Reference 6 | Koyo 7212B |
| Cross Reference 7 | Nachi 7212B |
SLF 7212 B.TVP is a single-row angular contact ball bearing. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Contact Angle: 40°. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Cage Material: Polyamide. Cage Type: One-piece window cage. Bearing Material: Chrome steel. Lubricant: Grease or oil. Series: 72. Base Number: 7212. Unit Quantity: 1 Pc. Boundary dimensions to DIN 628-1.
7212 — ISO 72 dimension series at a 60 mm bore, giving a 60 x 110 x 22 mm envelope.
B — 40° contact angle on a 72xx series bearing.
TVP — one-piece window cage in glass-fibre reinforced polyamide.
A 40° contact angle sits at the high-thrust end of the angular contact range. The steeper the angle, the more axial load the ball path carries and the lower the speed ceiling.
A single-row angular contact bearing takes axial load in one direction, so it is normally mounted against a second bearing that takes the other direction.
A one-piece polyamide window cage is light and quiet, and its low mass is what keeps the speed capability up on a 110 mm outside diameter.
Open on both faces, so the bearing draws its lubricant from the housing rather than a sealed-in grease charge.
Unit Quantity: 1 Pc. Single bearing, open, straight bore.
Cross-Reference 1: FAG 7212-B-TVP. Cross-Reference 2: FAG 7212-B-XL-TVP (related, X-life execution with higher ratings on the same envelope). Cross-Reference 3: SKF 7212 BECBP. Cross-Reference 4: NSK 7212B. Cross-Reference 5: NTN 7212B. Cross-Reference 6: Koyo 7212B. Cross-Reference 7: Nachi 7212B.
Every number above shares the 60 x 110 x 22 mm envelope and the 40° contact angle to DIN 628-1. The 7212 executions written with a C or an AC suffix are the 15° and 25° forms on the same envelope: they fit the same shaft and housing and move the load split between radial and axial, so they are related sizes.
Searchable designation forms: 7212B.TVP, 7212BTVP, 7212-B-TVP, 7212 B TVP, 7212B.
