Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Fafnir 7212WN-SU single-row angular contact ball bearing, 60 x 110 x 22 mm, 40 degree contact angle, open, pressed brass cage, universally ground.
List Price
$73.20
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Fafnir |
|---|---|
| MPN | 7212WN-SU |
| GTIN | 087796044104 |
| Model | 7212-WNSU |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Material | Bearing Steel |
|---|---|
| Series | 72 |
| Base Number | 7212WN |
| Bore Shaft Size | 60 mm |
| Mpn Variants | 7212WN-SU, 7212WN SU, 7212WNSU, 7212-WNSU, 7212 WN SU |
| Precision Class | ABEC 3 / P6 |
| Min Temp | -50 °C |
| Cage Type | Pressed |
| Dynamic Load Rating | 56,000 N |
| Static Load Rating | 44,500 N |
| Precision Rating | ABEC 3 / P6 |
| Rolling Elements | Balls |
| Max Temp | 120 °C |
| Cage Material | Brass |
| Limiting Speed | 4,720 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Contact Angle | 40° |
| Mounting Arrangement | Universal |
| Part Number | 7212WNSU |
| Industry Terms | Angular contact ball bearing; 40 degree angular contact bearing; universal ground bearing; single universal angular contact bearing |
| Common Misspellings | Fafner 7212WN-SU; Faffnir 7212WNSU; 7212 WN-SU; 7212WN SV; 7212 NW SU |
| Application Types | Machine tool spindles; pumps; thrust-loaded shafts |
| Cross Reference 1 | SKF 7212 BE - 40 degree contact angle |
|---|---|
| Cross Reference 2 | MRC 7212DU - 40 degree contact angle |
| Cross Reference 3 | Fafnir 7212WN MBR - machined bronze cage |
Fafnir 7212WN-SU single-row angular contact ball bearing, built by The Timken Company. Bore 60 mm, outside diameter 110 mm, width 22 mm, 40° contact angle, open, pressed brass cage, universally ground single bearing. Unit Quantity: 1 Pc. GTIN: 087796044104.
7212 — 60 mm bore, ISO 72 medium section, angular contact.
WN — 40° contact angle in Fafnir’s lettering system.
SU — a single bearing, universally ground, so any two pair back-to-back, face-to-face or in tandem.
Bore Diameter: 60 mm. Outside Diameter: 110 mm. Overall Width: 22 mm. Contact Angle: 40°. Series: 72. Base Number: 7212WN. Number Of Rows: 1. Rolling Elements: Balls. Bearing Material: Bearing steel. Bore Type: Straight. Closure Type: Open. Cage Material: Brass. Cage Type: Pressed. Precision Class: ABEC 3 / P6. Mounting Arrangement: Universal. Dynamic Load Rating: 56,000 N (12,600 lbf). Static Load Rating: 44,500 N (10,000 lbf). Limiting Speed: 4,720 rpm. Operating temperature range: -50 °C to 120 °C. Country of Origin: United States.
Envelope: 60 x 110 x 22 mm. Straight bore. Thrust direction: one direction, carried on the high shoulder side. Universal grinding: two bearings of the same designation pair back-to-back, face-to-face or in tandem.
Cross-Reference 1: SKF 7212 BE – 40 degree contact angle. Cross-Reference 2: MRC 7212DU – 40 degree contact angle. Cross-Reference 3: Fafnir 7212WN MBR – machined bronze cage. MPN Variants: 7212WN-SU, 7212WN SU, 7212WNSU, 7212-WNSU, 7212 WN SU.
40°. WN is the Fafnir code for 40°.
Single bearing, universally ground for paired mounting in any arrangement.
60 mm bore, 110 mm outside diameter, 22 mm width. Dynamic Load Rating: 56,000 N. Static Load Rating: 44,500 N.
