Availability:
1 in stock
Single row angular contact ball bearing, 65 mm bore, 120 mm OD, 23 mm wide, 15° contact angle. Open, straight bore, ISO 02 series, radial and one-way axial load.
List Price
$146.17
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7213CTCC78G1 |
| Model | 7213 CTC C78 G1 / 2M213WI CR |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 65 mm |
| OD | 120 mm |
| Width | 23 mm |
| Base Number | 7213 |
|---|---|
| Industry Terms | Spindle bearing; precision angular contact bearing; machine tool bearing; 72 series angular contact |
| Common Misspellings | 7213 CTC C78 GI; 7213CTCC78G-1; 7213 CTCC78 G1; 72 13 CTC C78; 7213CTCC7BG1 |
| Application Types | Machine tool spindles; gearbox shafts; pumps; screw drive supports |
| Overall Width | 23 mm |
| Mpn Variants | 7213CTCC78G1; 7213 CTC C78 G1; 7213-CTC-C78-G1; 7213CTC/C78G1; 7213C |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Bearing Material | Bearing steel |
| Cross Reference 1 | Timken/Fafnir 2MM213WICR |
|---|---|
| Cross Reference 2 | FAG B7213C.T.P4S |
| Cross Reference 3 | NSK 7213CTR |
| Cross Reference 4 | RHP B7213X2TA |
SKF single row angular contact ball bearing in the 72 series, ISO dimension series 02. Bore Diameter: 65 mm. Outside Diameter: 120 mm. Overall Width: 23 mm. Contact Angle: 15°. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Bearing Material: Bearing steel. Series: 7200. Base Number: 7213. Unit Quantity: 1 Pc.
72 — angular contact ball bearing to ISO dimension series 02.
13 — bore code. Bore diameter 65 mm.
C — 15° contact angle.
Contact Angle: 15°. The load line runs at 15° to the radial plane, so the bearing carries radial load together with axial load in one direction. The shallow angle favours running speed and radial stiffness. Ring Type: One-piece inner and outer rings.
ISO dimension series 02 at a 65 mm bore gives a 120 mm outside diameter and a 23 mm width. Single row angular contact bearings of this size run in machine tool spindles, gearbox shafts, pumps and screw drive supports, mounted in opposed pairs or in tandem so that thrust is taken in both directions.
Unit Quantity: 1 Pc. Single bearing, open on both faces, straight bore, one row of balls.
The cross-references listed are same-envelope, same-angle equivalents at 65 x 120 x 23 mm and 15°: Timken Fafnir 2MM213WICR, FAG B7213C.T.P4S, NSK 7213CTR, RHP B7213X2TA, NTN 7213C, Koyo 7213C, GMN S6213C, IBC 7213C.T and SNR 7213CG1.
