Availability:
1 in stock
Super-precision angular contact ball bearings, 20 x 47 x 14 mm, ISO 72 series, P4A precision, extra light preload. Two-bearing universally matchable DGA set.
List Price
$173.80
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7204CXP4ADGA |
| Model | 7204-CX-P4A-DGA |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 20 mm |
| OD | 47 mm |
| Width | 14 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Preload | Extra light |
| Total Width | 28 mm (two-bearing set) |
| Mpn Variants | 7204 CX/P4ADGA, 7204CXP4ADGA, 7204-CX-P4A-DGA, 7204 CX/P4A DGA |
| Arrangement Configuration | Universally matchable set of two |
| Precision Class | ABEC 7 / P4A |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
A set of two super-precision single row angular contact ball bearings in the ISO 72 series, SKF 7204 CX/P4ADGA. Bore Diameter: 20 mm. Outside Diameter: 47 mm. Overall Width: 14 mm per bearing. Total Width: 28 mm as a two-bearing stack. Number Of Rows: 1. Rolling Elements: Ball. Closure Type: Open. Bore Type: Straight.
72 — ISO dimension series 02, light section.
04 — bore code, 20 mm bore, giving the 20 x 47 x 14 mm envelope.
P4A — SKF precision class: ISO tolerance class 4 dimensional accuracy with running accuracy to a tighter level.
DG — set of two bearings for universal matching.
A — Extra light preload.
Preload: Extra light. Precision Class: ABEC 7 / P4A. The two bearings are matched as a set and mount back-to-back, face-to-face or in tandem at the extra light preload value.
Unit Quantity: 2 Pcs. One universally matchable DGA set of two bearings.
The 7204 envelope is 20 x 47 x 14 mm. Search designations for this part include 7204CXP4ADGA, 7204-CX-P4A-DGA and 7204 CX/P4A DGA.
