Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Super precision angular contact ball bearing, 70 x 100 x 16 mm, 25° contact angle, P4A tolerance, Extra light preload (200 N). SKF 719 series high-capacity D design.
List Price
$202.71
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 71914ACDP4ADGA |
| Model | 71914 AC D P4A DGA / 3MM 9314 WI DUL / 71914 A5 T DUL P4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 70 mm |
| OD | 100 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 71900 |
| Preload | Extra light (200 N) |
| Mpn Variants | 71914-ACDGA/P4A, 71914 ACDGA/P4A, 71914ACDGAP4A, 71914-ACD-GA-P4A, 71914-ACD-P4A-DGA, 7914 |
| Precision Class | ABEC 7 / P4A |
| Additional Attributes | Fatigue load limit 1,370 N; axial stiffness 180 N/µm; 24 balls of 9.525 mm; oil nozzle position 81.7 mm |
| Dynamic Load Rating | 32,500 N |
| Static Load Rating | 32,500 N |
| Rolling Elements | Ball |
| Item Weight | 0.328 kg (0.72 lb) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mounting Arrangement | Universally matchable: back-to-back, face-to-face or tandem |
| Bearing Material | Bearing steel |
| Cross Reference 1 | FAG B71914-E-T-P4S-UL |
|---|---|
| Cross Reference 2 | NSK 7914A5TYNSULP4 |
| Cross Reference 3 | Timken 3MM9314WI SUL |
SKF 71914 ACDGA/P4A is a super-precision, high-capacity single row angular contact ball bearing from the SKF 719 thin-section series. It is universally matchable and can be combined back-to-back, face-to-face or in tandem to give a predetermined extra light preload without shims.
71914 — 719 series angular contact ball bearing, 70 mm bore, 100 mm outside diameter.
ACD — high-capacity D design with a 25° contact angle.
GA — single bearing for universal matching, extra light preload.
P4A — SKF precision class: ISO P4 dimensional accuracy with tighter running accuracy.
Bore Diameter: 70 mm. Outside Diameter: 100 mm. Width: 16 mm. Contact Angle: 25°. Precision Class: ABEC 7 / P4A. Preload: Extra light, 200 N unmounted (back-to-back or face-to-face pair). Axial stiffness: 180 N/µm. Dynamic Load Rating: 32,500 N. Static Load Rating: 32,500 N. Fatigue load limit: 1,370 N. Ball diameter: 9.525 mm. Number of balls: 24. Reference grease quantity: 4.5 cm³. Item Weight: 0.328 kg (0.72 lb). Bearing Material: Bearing steel. Closure Type: Open.
Inner ring shoulder diameter d1: 79.2 mm. Outer ring shoulder diameter D1: 90.8 mm. Chamfer r1,2 min: 1 mm. Chamfer r3,4 min: 0.3 mm. Pressure point distance a: 27.9 mm. Shaft abutment da/db min: 74.6 mm. Housing abutment Da max: 95.4 mm; Db max: 98 mm. Fillet radius ra max: 1 mm; rb max: 0.3 mm. Oil nozzle position dn: 81.7 mm.
Unit Quantity: 1 Pc. Single universally matchable bearing.
Same envelope and 25° angle: FAG B71914-E-T-P4S-UL, NSK 7914A5TYNSULP4, Timken/Fafnir 3MM9314WI SUL. Cage execution and exact class vary by maker.
