Availability:
1 in stock
List Price
$51.45
1 in stock
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
Also Available From:
| MFR / Brand | RHP |
|---|---|
| MPN | 7203CTDULP4 |
| Model | B7203 C T P4S / 7203 CD P4A DGA / 2MM203WI DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 17mm |
| OD | 40mm |
| Width | 12mm |
| Series | 7200 |
|---|---|
| Condition | New |
| Lubricant | Oil |
| Preload | Light |
| Material | Bearing Steel |
| Bolt Center To Center | 5.5310 - 6.0830 in |
| Number Of Bolt Holes | 2 |
| Bolt Center To Center Length | 5.5310 - 6.0830 in |
| Number Of Bolt Holes For Fasteners | 2 |
| Centre Height Pillow Block | 2.125 in |
| Centre Height | 2.125 in |
| Min Temp | -30°C |
| Cage Type | TB - Phenolic |
| Dynamic Load Rating | 10.1 kN / 2270 lbf |
| Static Load Rating | 5.3 kN / 1190 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Balls |
| Max Temp | 120°C |
| Item Weight | 0.15 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 36000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Duty Type | Standard Duty |
| Locking Device | Set Screw |
| Relubrication Feature | Yes |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Housing Material | Cast Iron |
| Expansion Type | Non-Expanding |
| Internal Clearance | CN |
| Cross Reference 1 | SKF 7203 CD/P4A |
|---|---|
| Cross Reference 2 | FAG B7203-C-T-P4S |
| Cross Reference 3 | NSK 7203CTYNSULP4 |
| Cross Reference 4 | NTN 7203C |
| Cross Reference 5 | GMN S6203 C TA P4 |
Pillow Block Unit – 1.75 in Bore, 2 bolt holes, Cast Iron housing, Standard Duty, Non-Expanding.
