Availability:
1 in stock
Deep groove ball bearing, 45x75x16 mm, ABEC 7 / P4 precision, open. Dynamic load rating 23,000 N, static 15,200 N. Limiting speed 10,000 rpm grease.
List Price
$114.72
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 6009TCG12P4 |
| GTIN | 029176624483 |
| Model | 6009 TC G12 P4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 45 mm |
| OD | 75 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 6000 |
| Base Number | 6009 |
| Industry Terms | Deep groove ball bearing; precision ball bearing; radial ball bearing; single row ball bearing |
| Common Misspellings | 6009TGC12P4; 6009 TC GI2 P4; 60O9TCG12P4; 6009TCG12-P4 |
| Application Types | Electric motors; pumps; gearboxes; light spindle and instrument drives |
| Overall Width | 16 mm |
| Mpn Variants | 6009TCG12P4; 6009-TC-G12-P4; 6009 TC G12 P4; 6009P4 |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | 13 balls of 8.731 mm diameter; shaft abutment da 50 to 53.5 mm; housing abutment Da max 70 mm; chamfer r min 1 mm; max shaft and housing fillet radius ra 1 mm |
| Dynamic Load Rating | 23,000 N |
| Static Load Rating | 15,200 N |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 10,000 rpm grease; 12,000 rpm oil |
| Lubricant | Grease or oil |
| Harmonization Code | 8482.10.50.68 |
| Bearing Material | Bearing steel |
| Cross Reference 1 | SKF 6009 |
|---|---|
| Cross Reference 2 | FAG 6009 |
| Cross Reference 3 | NTN 6009 |
| Cross Reference 4 | Timken 6009 |
| Cross Reference 5 | Koyo 6009 |
| Cross Reference 6 | RHP 6009 |
| Cross Reference 7 | NACHI 6009 |
NSK 6009 single-row deep groove ball bearing in a P4 precision execution. Bore Diameter: 45 mm. Outside Diameter: 75 mm. Overall Width: 16 mm. Precision Class: ABEC 7 / P4. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Closure Type: Open. Bearing Material: Bearing steel.
6009 — ISO 60-series deep groove ball bearing, 45 x 75 x 16 mm. A deep groove bearing carries radial load with moderate axial capacity in either direction and has no contact angle.
P4 — ISO class 4, ABEC 7.
Dynamic Load Rating: 23,000 N (5,171 lbf). Static Load Rating: 15,200 N (3,417 lbf). Ratings are per bearing.
Limiting Speed: 10,000 rpm grease; 12,000 rpm oil. Lubricant: grease or oil.
The complement is 13 balls of 8.731 mm diameter. Item Weight: 0.241 kg (0.53 lb) per bearing.
ABEC 7 running accuracy on a deep groove envelope suits light spindle and instrument duty where a standard-class 6009 would run with too much radial runout.
Shaft abutment diameter da: 50 to 53.5 mm. Housing abutment diameter Da max: 70 mm. Bearing chamfer r min: 1 mm. Maximum shaft and housing fillet radius ra: 1 mm.
Unit Quantity: 1 Pc.
The 6009 envelope is an ISO standard size, so SKF 6009, FAG 6009, NTN 6009, Timken 6009, Koyo 6009 and RHP 6009 all share the 45 x 75 x 16 mm boundary dimensions. Those are catalogue-standard executions; this listing is the P4 precision execution.
