Super-precision angular contact ball bearing, 65 x 120 x 23 mm, 15° contact angle, ABEC 7 / P4, phenolic cage, open. Single bearing for machine tool spindles.
List Price
$175.12
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Fafnir |
|---|---|
| MPN | 2MM213WN CR |
| Model | MM 213 WI CR / 7213 B P4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 65 mm |
| OD | 120 mm |
| Width | 23 mm |
| Material | Bearing Steel |
|---|---|
| Series | 2MM200 |
| Base Number | 2MM213 |
| Industry Terms | spindle bearing, super precision angular contact, phenolic cage bearing, machine tool bearing |
| Application Types | Machine tool spindles, grinding spindles, high-speed milling heads, precision rotary tables |
| Bore Shaft Size | 65 mm |
| Mpn Variants | 2MM213WNCR, 2MM-213-WN-CR, 2MM213WN CR, 2MM213WICR, 2MM213, 7213C |
| Manufacturer Status | Fafnir precision bearings are now supplied under the Timken brand |
| Precision Class | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Part Number | 2MM213WN CR |
| Cross Reference 1 | FAG B7213-C-T-P4S - P4S class |
|---|---|
| Cross Reference 2 | NSK 7213CTYNSULP4 - polyamide cage, universal light preload |
| Cross Reference 3 | SKF 7213 CDGA/P4A - P4A class, preload class A |
Fafnir (Timken) 2MM213WN CR is a single-row super-precision angular contact ball bearing in the ISO 7213 envelope. Bore Diameter: 65 mm. Outside Diameter: 120 mm. Overall Width: 23 mm. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Cage Material: Phenolic. Closure Type: Open. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Series: ISO 72xx. Unit Quantity: 1 Pc.
2MM — Fafnir super-precision series with a 15° contact angle and P4 tolerance.
213 — ISO 7213 size, 65 x 120 x 23 mm.
CR — phenolic cage.
Contact Angle: 15°. This angle favours high speed, low friction and radial stiffness, with moderate axial capacity.
Cage Material: Phenolic. A phenolic cage is light and quiet, which keeps centrifugal loading low at spindle speeds.
Unit Quantity: 1 Pc. Single bearing; the designation carries no universal-grinding or preload group.
Same 65 x 120 x 23 mm envelope and 15° contact angle: FAG B7213-C-T-P4S, NSK 7213CTYNSULP4, SKF 7213 CDGA/P4A. 3MM213 is the 25° version of this envelope. Searchable variants: 2MM213WNCR, 2MM-213-WN-CR, 2MM213WN CR, 2MM213WICR, 2MM213, 7213C.
