Name: Spindle Angular Contact Ball Bearing - 30 mm ID, 55 mm OD, 13 mm Width, Open, 25°, Light Preload
Brand: SKF
SKU: B-AO3B1#PJ6JZ8
Price: 206.51 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	SKF
MPN	7006ACXP4ADGA
Model	7006 A CX P4A DGA 7006ACXGAP4A
Bearing Type	Angular Contact Ball Bearing, Open
ID	30 mm
OD	55 mm
Width	13 mm

Specifications

Advertise	1
Material	High Carbon Chrome Steel
Series	7000
Condition	New
Lubricant	Oil
Preload	Light
Min Temp	-30 °C
Cage Type	Ball Centered
Dynamic Load Rating	13.3 kN / 2990 lbf
Static Load Rating	8.8 kN / 1980 lbf
Precision Rating	ABEC 7 / P4
Rolling Elements	Ball
Max Temp	150 °C
Item Weight	0.26 lbs
Cage Material	Machined Brass
Limiting Speed	34000 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	25°
Mounting Arrangement	Universal

Cross-References

Cross Reference 1	FAG B7006-E-T-P4S-DUL
Cross Reference 2	NSK 7006ETYNDULP4
