Name: Spherical Roller Bearing - Tapered Bore, 60mm ID, 110mm OD, 28mm Width, Open, High Load (HL) Capacity.
Brand: RHP
SKU: EH2B2#ACHZUQ
Price: 53.52 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	RHP
MPN	22212HLK
Model	22212 HL K 22212MB 22212M
Bearing Type	Spherical Roller Bearing, Open
ID	60mm
OD	110mm
Width	28mm

Specifications

Advertise	1
Series	22200
Condition	New – Open box
Material	Bearing Steel
Min Temp	-30°C
Cage Type	One-Piece
Dynamic Load Rating	134 kN / 30100 lbf
Static Load Rating	141 kN / 31700 lbf
Precision Rating	ABEC 1 / P0
Rolling Elements	Spherical Rollers
Max Temp	200°C
Item Weight	2.54 lbs
Cage Material	Steel
Limiting Speed	6300 rpm
Number Of Rows	2
Bore Type	Tapered
Snap Ring Included	Without Snap Ring
Relubrication Feature	Yes
Harmonization Code	8482.30.00
Internal Clearance	CN
Maximum Permissible Misalignment	2°

Cross-References

Cross Reference 1	SKF 22212 EK
Cross Reference 2	FAG 22212-E1-K
Cross Reference 3	NTN 22212EAKD1
Cross Reference 4	NSK 22212EAKE4
Cross Reference 5	Timken 22212K
