Photo may not represent actual item. Refer to name and product specs for all details.
Availability:
1 in stock
List Price
$41.66
1 in stock
1 in stock
Get Estimated Arrival Date
| MFR / Brand | NSK |
|---|---|
| MPN | 7206A5TYDULPA7 |
| Model | 7206 A5 TY DUL PA7 / 3MM206 WI CR DUL / B7206E |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 30 mm |
| OD | 62 mm |
| Width | 16 mm |
| Cage Type | Molded |
|---|---|
| Dynamic Load Rating | 20.3 kN / 4563 lbf |
| Static Load Rating | 14.9 kN / 3349 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | 7200 |
| Rolling Elements | Ball |
| Max Temp | 120°C |
| Condition | New – Open box |
| Item Weight | 0.46 lbs |
| Cage Material | Polyamide |
| Limiting Speed | 26000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Lubricant | Oil |
| Contact Angle | 25° |
| Preload | Light |
| Mounting Arrangement | Universal |
| Material | Chrome Steel |
Angular Contact Ball Bearing – 30 mm ID, 62 mm OD, 16 mm Width, Open, 25° Contact Angle, P4 Precision
