Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

NDH

613Z

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Condition: New – Open box

Model #: 613 Z

Availability:

1 in stock

Categories: Uncategorized

Product Description

Deep Groove Ball Bearing – Straight Bore, 65 mm ID, 140 mm OD, 33 mm Width, Single Shield, Without Snap Ring

Same day shipment

List Price

$67.18

1 in stock

Also Available From:

Need Help?
Click Here To Contact Support

Specifications

Additional information

Key Specifications

MFR / Brand	NDH
MPN	613Z
Model	613 Z
Bearing Type	Ball Bearing, Single Shield
ID	65 mm
OD	140 mm
Width	33 mm

Specifications

Advertise	1
Cage Type	Pressed Steel
Dynamic Load Rating	92.3 kN / 20750 lbf
Static Load Rating	59.7 kN / 13421 lbf
Precision Rating	ABEC 1 / P0
Series	6300
Rolling Elements	Balls
Max Temp	120°C
Condition	New – Open box
Item Weight	4.60 lbs
Limiting Speed	4300 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	No
Lubricant	Grease
Internal Clearance	CN

Cross-References

Cross Reference 1	SKF 6313-Z
Cross Reference 2	FAG 6313-Z
Cross Reference 3	NTN 6313Z
Cross Reference 4	KOYO 6313Z
Cross Reference 5	NSK 6313Z

Seller Part Number: AI6B2#LCGTGB
