Phoenix Contact 2313669 SHDSL industrial modem for RS-232/422/485 serial links up to 2000 kbps over 20 km of in-house copper, with USB diagnostics and two alarm outputs.
List Price
$125.59
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Phoenix Contact |
|---|---|
| MPN | PSI-MODEM-SHDSL/SERIAL |
| Model | PSI-MODEM-SHDSL/SERIAL |
| Condition Note | See Pictures |
|---|---|
| Condition | Used |
| Additional Attributes | RS-232 Transmission Speed: up to 230.4 kbps; RS-422/RS-485 Transmission Speed: up to 2000 kbps; SHDSL: 64 kbps-30 Mbps 4-wire, 32 kbps-15.3 Mbps 2-wire; Distance: up to 20 km; Alarm Outputs: 2; Diagnostics: USB and LEDs |
| Industry Terms | SHDSL extender, serial line extender, industrial modem, RS-485 extender |
| Common Misspellings | Phoenix-Contact, Pheonix Contact, PSI-MODEM-SHDSL SERIAL |
| Application Types | Long-distance serial networking, SCADA, remote I/O, water and wastewater telemetry |
| Mpn Variants | PSI-MODEM-SHDSL/SERIAL, 2313669, PSI MODEM SHDSL SERIAL, PSIMODEMSHDSLSERIAL |
Phoenix Contact PSI-MODEM-SHDSL/SERIAL, order number 2313669. Industrial SHDSL extender for serial RS-232, RS-422 and RS-485 interfaces, built for point-to-point and line structures over in-house copper cable.
PSI-MODEM — Phoenix Contact PSI industrial modem and extender family.
SHDSL — symmetrical high-speed DSL line interface on the long-distance side.
SERIAL — serial device-side interface: RS-232, RS-422 and RS-485.
2313669 — Phoenix Contact order number for this exact device.
RS-232 Transmission Speed: up to 230.4 kbps. RS-422 Transmission Speed: up to 2000 kbps. RS-485 Transmission Speed: up to 2000 kbps. SHDSL Transmission Speed: 64 kbps to 30 Mbps in 4-wire operation; 32 kbps to 15.3 Mbps in 2-wire operation. Transmission Distance: up to 20 km. Alarm Outputs: 2 configurable digital outputs for signalling an external controller. Diagnostics: USB and LEDs.
The SHDSL modulation carries serial data over existing twisted-pair plant where standard RS-485 distance limits are exceeded.
Mounting: DIN rail, with optional DIN rail bus connector ME 17,5 TBUS 1,5/ 5-ST-3,81 GN (2709561) for supply bussing.
Related Phoenix Contact accessories: DT-TELE-SHDSL surge protection (2801593), CABLE-USB/MINI-USB-3,0M programming cable (2986135), SUBCON 9/M-SH D-SUB connector (2761509), QUINT4-SYS-PS/1AC/24DC/2.5/SC power supply (2904614).
