SKF7006 CX/P4ADGASuper-Precision Angular Contact Ball Bearing Pair – 30 mm ID, 55 mm OD, 13 mm Width, Extra Light Preload, Open, P4A

Product Description

What this part is:

SKF 7006 CX/P4ADGA is a matched pair of super-precision single-row angular contact ball bearings, ISO 70 series size 7006. Bore 30 mm, outside diameter 55 mm, width 13 mm each, open on both faces, universally matchable. Unit Quantity: 2 Pcs.

Decoding the designation:

7006 — ISO 70 series size code, 30 x 55 x 13 mm.

P4A — SKF super-precision tolerance class, equivalent to ABEC 7.

DGA — universally matchable set, extra light preload.

Specifications:

Bore Diameter: 30 mm. Outside Diameter: 55 mm. Width: 13 mm per bearing. Total Width: 26 mm (pair). Number Of Rows: 1 per bearing. Precision Class: ABEC 7 / P4A. Preload: Extra light. Closure Type: Open. Rolling Elements: Steel balls. Material: Chrome steel. Series: 7000 (ISO 70).

Dimensions and mounting:

Matching: universally matchable set; the published extra light preload applies when the pair is set adjacent in any arrangement.

Frequently asked questions:

What size is the SKF 7006 CX/P4ADGA?

Each bearing is 30 mm bore, 55 mm outside diameter and 13 mm wide; the pair measures 26 mm total width.

How many bearings are in this listing?

Unit Quantity: 2 Pcs, supplied as a matched pair.

What does DGA mean in this designation?

DGA marks a universally matchable set with extra light preload.
