Availability:
1 in stock
Spherical roller bearing, 45 x 100 x 25 mm, 1:12 tapered bore, C3 clearance, open, two roller rows. Mounts on an H309 adapter sleeve for a 45 mm shaft seat.
List Price
$60.53
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 21309K.C3 |
| Model | 21309-K-C3 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 45 mm |
| OD | 100 mm |
| Width | 25 mm |
| Series | 21300 |
|---|---|
| Closure Type | Open |
| Rolling Elements | Spherical Roller |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | No |
| Relubrication Feature | Yes |
| Harmonization Code | 8482.30.00 |
| Internal Clearance | C3 |
| Common Misspellings | 21309K C3, 21309-KC3 |
| Overall Width | 25 mm |
| Mpn Variants | 21309K.C3, 21309-K-C3, 21309KC3, 21309 K C3, 21309-E1-K-C3, 21309-E1-XL-K-C3 |
| Compatible With Replaces | Successor: FAG 21309-E1-XL-K-C3; adapter sleeve H309 |
| Lubricant | grease or oil |
| Industry Terms | spherical roller bearing, self-aligning roller bearing, tapered bore spherical bearing, adapter sleeve bearing, double row roller bearing |
| Application Types | Gearboxes; conveyors; fans and blowers; pumps; vibrating screens; general heavy-duty shaft support |
| Cross Reference 1 | SKF 21309 EK/C3 (E design) |
|---|---|
| Cross Reference 2 | NSK 21309EAKE4C3 (EA design) |
FAG 21309K.C3 spherical roller bearing with a 1:12 tapered bore and C3 internal clearance: 45 mm bore, 100 mm outside diameter, 25 mm width, open. Mounts on an H309 adapter sleeve for a tapered 45 mm bore.
213 — spherical roller bearing, 13 dimension series, 100 mm OD section for a 45 mm bore.
09 — bore code, 45 mm bore.
K — tapered bore, taper 1:12.
C3 — radial internal clearance greater than normal.
Bore Diameter: 45 mm. Outside Diameter: 100 mm. Overall Width: 25 mm. Rolling Elements: Spherical Roller. Number Of Rows: 2. Bore Type: Tapered 1:12. Internal Clearance: C3. Closure Type: Open. Lubricant: grease or oil. Unit Quantity: 1 Pc.
Envelope: 45 x 100 x 25 mm. Adapter sleeve: H309.
Same 45 x 100 x 25 mm tapered-bore C3 envelope: SKF 21309 EK/C3 (E design), NSK 21309EAKE4C3 (EA design). Later Schaeffler design: 21309-E1-XL-K-C3.
A 1:12 tapered bore.
The H309 adapter sleeve, for the tapered 45 mm bore.
C3, a radial internal clearance greater than normal.
