SKF 7022 ACDGA/P4A super-precision angular contact bearing, 110 x 170 x 28 mm, 25° angle, extra light preload, P4A. Dynamic rating 104,000 N, static 104,000 N.
List Price
$1,200.23
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7022ACDGAP4A |
| Model | 7022ACDGA/P4A |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 170 mm |
| Width | 28 mm |
| Material | Steel |
|---|---|
| Series | 7000 |
| Preload | Extra light (GA) |
| Mpn Variants | 7022 ACDGA/P4A, 7022ACDGAP4A, 7022-ACDGA-P4A, 7022-ACDGA/P4A |
| Precision Class | P4A (ABEC 7 / P4 dimensional, P2 running accuracy) |
| Dynamic Load Rating | 104,000 N |
| Static Load Rating | 104,000 N |
| Precision Rating | P4A (ABEC 7 / P4 dimensional, P2 running accuracy) |
| Rolling Elements | Ball |
| Item Weight | 1.93 kg (4.25 lb) per bearing |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 25° |
| Mounting Arrangement | Universal: back-to-back, face-to-face or tandem |
| Bearing Material | Bearing steel |
| Cross Reference 1 | FAG B7022-E-T-P4S |
|---|---|
| Cross Reference 2 | NSK 7022A5 |
| Cross Reference 3 | NTN 7022AD |
| Cross Reference 4 | Fafnir 3MM9122WI |
SKF 7022 ACDGA/P4A is a super-precision, high-capacity single row angular contact ball bearing in the 70 series, with a 25° contact angle and extra light preload for universal matching. It carries combined radial and one-direction axial load in machine tool spindles.
70 — ISO dimension series 10, light section.
22 — bore code, 22 x 5 = 110 mm bore.
ACD — 25° contact angle, high-capacity D design.
GA — single bearing for universal matching, extra light preload. Any two GA bearings mount back-to-back, face-to-face or in tandem.
P4A — SKF tolerance class: ISO P4 dimensional accuracy with ISO P2 running accuracy.
Bore Diameter: 110 mm. Outside Diameter: 170 mm. Width: 28 mm. Contact Angle: 25°. Dynamic Load Rating: 104,000 N. Static Load Rating: 104,000 N. Preload: Extra light (GA). Precision Class: P4A (ABEC 7 / P4 dimensional, P2 running accuracy). Number Of Rows: 1. Contact Type: Normal two-point contact. Design: High-capacity D. Bearing Material: Bearing steel. Closure Type: Open. Item Weight: 1.93 kg (4.25 lb) per bearing.
The 25° angle gives higher axial capacity and axial stiffness than a 15° bearing of the same size. Extra light preload keeps heat generation low at spindle speeds.
Universally matchable bearings: back-to-back, face-to-face or tandem with any other 7022 ACDGA bearing.
Same envelope, 25° angle, super-precision class: FAG B7022-E-T-P4S, NSK 7022A5, NTN 7022AD, Fafnir 3MM9122WI, SNFA VEX 110 7CE3. MPN variants: 7022 ACDGA/P4A, 7022ACDGAP4A, 7022-ACDGA-P4A, 7022-ACDGA/P4A. Harmonization Code: 8482.10.50.
