Availability:
Out of stock
List Price
$61.18
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
Also Available From:
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Super Precision Angular Contact Ball Bearing 60x110x22 mm, 15° Contact Angle, Light Preload, ABEC 7, Half of a Duplex Pair Original price was: $149.88.$112.41Current price is: $112.41.
Super Precision Angular Contact Ball Bearing - Straight Bore, 60 mm ID, 110 mm OD, 22 mm Width, Open, 15 Degree Contact Angle, Universal Matchable Duplex Pair, Light Preload, Laminated Phenolic Cage Original price was: $299.76.$224.82Current price is: $224.82.
Super Precision Angular Contact Ball Bearing 60x110x22 mm, 15° Contact Angle, Phenolic Cage, ABEC 7 / P4S, Universally Ground Original price was: $89.85.$67.39Current price is: $67.39.
Angular Contact Ball Bearing 60x110x22 mm 15° Light Preload Duplex Ground Half Pair Original price was: $149.88.$112.41Current price is: $112.41.| MFR / Brand | RHP |
|---|---|
| MPN | 7212CTDULP4 |
| Model | 7212 C T DUL P4 / 2MM212 WI CR DUL / 212HDL / 7212CDP4ADGA |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 110 mm |
| Width | 22 mm |
| Series | 7200 |
|---|---|
| Condition | New – Open box |
| Preload | Light |
| Material | Bearing Steel |
| Condition Note | Made In England, New Old Stock |
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 61 kN / 13700 lbf |
| Static Load Rating | 49.5 kN / 11130 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Balls |
| Max Temp | 120 °C |
| Item Weight | 1.75 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Duplex Universal |
| Limiting Speed | 15000 rpm |
| Cross Reference 1 | SKF 7212 CD/P4A |
|---|---|
| Cross Reference 2 | Fafnir 2MM212WI |
| Cross Reference 3 | NSK 7212CTYNSULP4 |
Angular Contact Bearing – 60 mm ID, 110 mm OD, 22 mm Width, Open, 15° Contact Angle
Original price was: $299.76.$224.82Current price is: $224.82.
5 in stock
Original price was: $299.76.$224.82Current price is: $224.82.
5 in stock
