Angular Contact Spindle Bearing – 65 mm Bore, 120 mm OD, 23 mm Width, 15° Contact Angle, ABEC 7 / P4$68.83
Angular Contact Ball Bearing - 65 mm ID, 120 mm OD, 23 mm Width, 15° Contact Angle, Light Preload, P4S$186.79
Angular Contact Ball Bearing - 65 mm ID, 120 mm OD, 23 mm Width, 15° Contact Angle, Extra Light Preload, ABEC 7 / P4$186.79
Super-Precision Angular Contact Ball Bearings - 65 mm ID, 120 mm OD, 23 mm Width, 15° Contact Angle, Open, Light Preload, 2 Pcs$381.10| MFR / Brand | RHP |
|---|---|
| MPN | 7213TDULP4 |
| Model | 7213 T DUL P4 / MM213WI CR DUL / B7213X2-TA-U-EP7 / 7213B |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 65 mm |
| OD | 120 mm |
| Width | 23 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Preload | Light |
| Min Temp | -40 °C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 68.5 kN |
| Static Load Rating | 59.5 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 2.16 lbs |
| Cage Material | Phenolic Resin |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15 °C |
| Mounting Arrangement | Universal |
| Internal Clearance | CN |
| Limiting Speed | 17300 rpm |
| Cross Reference 1 | SKF 7213 CDGA/P4A |
|---|---|
| Cross Reference 2 | FAG B7213-C-T-P4S-UL |
| Cross Reference 3 | NSK 7213CTYNSULP4 |
