Availability:
Out of stock
List Price
$53.42
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing Duplex Pair - 45 mm ID, 85 mm OD, 19 mm Width, 15° Contact Angle, Light Preload, ABEC 7/9 P4S$43.55
Angular Contact Ball Bearing Duplex Pair - 45 mm ID, 85 mm OD, 19 mm Width, 15° Contact Angle, Light Preload, ABEC 7/9 P4S$51.26
Super-Precision Angular Contact Ball Bearing Matched Pair - Straight Bore, 45 mm ID, 85 mm OD, 19 mm Width, Open, 15° Contact Angle, Light Preload, Phenolic Cage.$97.53
Angular Contact Ball Bearing - 45 mm ID, 85 mm OD, 19 mm Width, Open, 15° Contact Angle, Light Preload.$224.74| MFR / Brand | Fafnir |
|---|---|
| MPN | 2MM209WIDUL |
| Model | 2-MM-209-WI-DUL / 7209C T P4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 45 mm |
| OD | 85 mm |
| Width | 19 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Lubricant | Oil |
| Preload | Light |
| Min Temp | -30°C |
| Cage Type | Phenolic |
| Dynamic Load Rating | 33.5 kN |
| Static Load Rating | 22.5 kN |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Max Temp | 120°C |
| Item Weight | 0.90 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Limiting Speed | 20000 rpm |
| Cross Reference 1 | SKF 7209 CDGA/P4 |
|---|---|
| Cross Reference 2 | NSK 7209CTYNSULP4 |
Introducing the Fafnir 2MM209WID-SUL Bearing, a top-quality Angular Contact Ball Bearing that is designed to deliver exceptional performance in various applications. With precise dimensions of 45x85x19 mm, this bearing is specifically engineered to meet the high demands of your machinery and equipment. Key features of the Fafnir 2MM209WID-SUL include: Brand: FAFNIR Model: 2-MM-209-WI-DUL / 7209C T P4 MPN: 2MM209WIDUL Country of Manufacture: United States Width: 19 mm This new and open box bearing assures reliable operation for your applications, providing efficient load handling and reduced friction for smoother functioning. It is perfect for those who seek durable and high-performance bearings. We understand how crucial it is to have the right parts. If you cannot find the component you need, please do not hesitate to contact us. We can source all parts at competitive prices, ensuring that you have access to a wide range of products. Enjoy the benefits of international shipping on every order, along with combined shipping options to save costs. We offer same-day shipping for all items, and next day shipping options are available during checkout. Invest in the Fafnir 2MM209WID-SUL Bearing for unparalleled performance and reliability in your applications.
