The product is a high-quality angular contact ball bearing manufactured by SKF in Italy. With a bore diameter of 110mm, an outside diameter of 170mm, and a width of 28mm, this bearing is designed for industrial automation and motion control applications. Made of durable steel material, it boasts a high precision level with ABEC7 tolerance class. Ideal for ensuring smooth and efficient mechanical power transmission, the SKF 7022-CD/HCP4ATBTA bearing is a reliable choice for various industrial settings.ID: 110 mm ≈ 4 5/16″ ≈ 4.331″OD: 170 mm ≈ 6 11/16″ ≈ 6.693″W: 28 mm ≈ 1 7/64″ ≈ 1.102″
List Price
$1,800.33
1 in stock
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
Also Available From:
| MFR / Brand | SKF |
|---|---|
| MPN | 7020CEP4AQBCB |
| Model | 7022CD/HCP4A TBTA |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 110 mm |
| OD | 170 mm |
| Width | 28 mm |
| Material | Steel |
|---|---|
| Min Temp | -30 °C |
| Cage Type | Machined |
| Dynamic Load Rating | 85.8 kN / 19300 lbf |
| Static Load Rating | 73.5 kN / 16500 lbf |
| Precision Rating | ABEC 7 / P4 |
| Series | 7000 |
| Rolling Elements | Ceramic Balls |
| Max Temp | 120 °C |
| Condition | New |
| Item Weight | 4.10 lbs |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Preload | Light |
| Mounting Arrangement | Universal |
| Cross Reference 1 | Fafnir 2MMVC9122HX |
|---|---|
| Cross Reference 2 | NSK 7022CTYNSULP4 |
| Cross Reference 3 | GMN HYS6022CTA |
