Name: Angular Contact Ball Bearing - 70 mm ID, 125 mm OD, 24 mm Width, Open, 15°.
Brand: SKF
SKU: AP2B5#QBYIRA
Price: 143.14 USD
Availability: InStock

Additional information

Key Specifications

MFR / Brand	SKF
MPN	7214CTCC78G5
Model	7214 CTC C78 G5 / 2M214WI CR
Bearing Type	Angular Contact Ball Bearing, Open
ID	70 mm
OD	125 mm
Width	24 mm

Specifications

Advertise	1
Material	Bearing Steel
Series	7200
Condition	New – Open box
Condition Note	Made In USA, New Old Stock
Min Temp	-30°C
Cage Type	Outer Ring Guided
Dynamic Load Rating	78 kN / 17535 lbf
Static Load Rating	72 kN / 16186 lbf
Precision Rating	ABEC 5 / P5
Rolling Elements	Ball
Max Temp	120°C
Item Weight	2.40 lbs
Cage Material	Phenolic Resin
Limiting Speed	9500 rpm
Number Of Rows	1
Bore Type	Straight
Snap Ring Included	Without Snap Ring
Harmonization Code	8482.10.50
Contact Angle	15°

Cross-References

Cross Reference 1	FAG B7214-C-P5
Cross Reference 2	NSK 7214CTYNP5
Cross Reference 3	NTN 7214CP5
